BGP7
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B7JF71110100 | STAND MAIN | ₹ 577 | 1 | ||
| 2 | B7JF71120000 | SHAFT MAIN STAND | ₹ 63 | 1 | ||
| 3 | 990020960000 | CIRCLIP | ₹ 4 | 1 | ||
| 4 | 905063582800 | SPRING TENSION | ₹ 48 | 1 | ||
| 5 | B7JF72540000 | HOOK | ₹ 18 | 1 | ||
| 6 | B7JF72670000 | GUIDE WIRE | ₹ 34 | 1 | ||
| 7 | B7JF74810000 | BOARD FOOTREST | ₹ 447 | 1 | ||
| 8 | 904801339800 | GROMMET | ₹ 10 | 2 | ||
| 9 | 901090620200 | BOLT | ₹ 13 | 4 | ||
| 10 | 901830681800 | NUT SPRING | ₹ 23 | 1 | ||
| 11 | 901830580700 | NUT SPRING | ₹ 9 | 9 | ||
| 12 | B7JF74880000 | BOARD FOOTREST 2 | ₹ 193 | 1 | ||
| 13 | 977025001200 | SCREW TAPPING | ₹ 11 | 5 | ||
| 14 | 901830580700 | NUT SPRING | ₹ 9 | 6 | ||
| 15A | B7JXF74900PG | MOLE, SIDE 1 ASSY. | ₹ 435 | 1 | FOR MLNM4 | |
| 15B | B7JXF74900P8 | MOLE SIDE 1 ASSY. | ₹ 242 | 1 | FOR MBL2 | |
| 16 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 17 | 902690681300 | RIVET | ₹ 8 | 1 | ||
| 18A | B7JXF74F00PF | MOLE, SIDE 2 ASSY. | ₹ 435 | 1 | FOR MLNM4 | |
| 18B | B7JXF74F00P8 | MOLE SIDE 2 ASSY. | ₹ 242 | 1 | FOR MBL2 | |
| 19 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 20 | 902690681300 | RIVET | ₹ 8 | 1 | ||
| 21 | B7JF74310000 | FOOTREST REAR 1 | ₹ 181 | 1 | ||
| 22 | 1GCF74330200 | COVER, REAR FOOTREST | ₹ 59 | 1 | ||
| 23 | 1GCF74450000 | PLATE 1 | ₹ 10 | 1 | ||
| 24 | 902400681100 | PIN CLEVIS | ₹ 12 | 1 | ||
| 25 | 904681200700 | CLIP | ₹ 10 | 1 | ||
| 26 | B7JF74410000 | FOOTREST REAR 2 | ₹ 181 | 1 | ||
| 27 | 1GCF74440200 | COVER, REAR FOOTREST | ₹ 59 | 1 | ||
| 28 | 1GCF74460000 | PLATE 2 | ₹ 10 | 1 | ||
| 29 | 902400681100 | PIN CLEVIS | ₹ 12 | 1 | ||
| 30 | 904681200700 | CLIP | ₹ 10 | 1 | ||
| 31 | B7JF73110000 | STAND SIDE | ₹ 226 | 1 | ||
| 32 | 905062081800 | SPRING TENSION | ₹ 20 | 1 | ||
| 33 | B7JF72170000 | BOLT | ₹ 41 | 1 | ||
| 34 | 956021020000 | NUT U FLANGE | ₹ 32 | 1 | ||
| 35 | B7JH21290000 | COVER BATTERY | ₹ 44 | 1 | ||
| 36 | 977025001600 | SCREW TAPPING | ₹ 10 | 2 | ||
| 37 | B7JH212B0000 | BOX BATTERY 1 | ₹ 66 | 1 | ||
| 38 | 90119068D400 | BOLT WITH WASHER | ₹ 7 | 1 | ||
| 39 | 905200881400 | DAMPER PLATE | ₹ 14 | 1 | ||
| 40 | B7JH211A0100 | ROPE | ₹ 9 | 1 | ||
| 41 | B7JF15680000 | LABEL WARNING | ₹ 6 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - This Yamaha Fascino Stand & Footrest assembly offers durability and convenience. It features the Main Stand, Side Stand, and the Footrest Board for the rider. The kit includes specialized Mole Side assemblies and high-quality Rear Footrests for passenger comfort. Mechanical reliability is ensured by the Shaft Main Stand and various Tension Springs. All mounting hardware, including Rivets and Nut Springs, is provided to restore your scooter’s parked stability and riding ergonomics.
