CRANKSHAFT & PISTON
D782
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 1WDE14111000 | CRANKSHAFT | ₹ 20663 | 1 | ||
| 2 | 1WD116500000 | CONNECTING ROD ASSY | ₹ 3198 | 2 | ||
| 3 | 5SL116540000 | BOLT CONNECTING ROD | ₹ 295 | 2 | ||
| 4 | 901790765200 | NUT | ₹ 65 | 2 | ||
| 5A | 1WD116560000 | PLANE BEARING CONNECTING ROD( | ₹ 330 | 4 | BLUE | |
| 5B | 1WD116561000 | PLANE BEARING, CONNECTING ROD | ₹ 330 | 4 | BLACK | |
| 5C | 1WD116562000 | PLANEBEARING CONNECTINGROD(BRO | ₹ 330 | 4 | BROWN | |
| 5D | 1WD116563000 | PLANEBEARINGCONNECTINGROD(GREE | ₹ 330 | 4 | GREEN | |
| 6 | 1WDE15360000 | GEAR, DRIVE | ₹ 1835 | 1 | ||
| 7 | 1WDE15490000 | SPROCKET CAM CHAIN | ₹ 289 | 1 | ||
| 8 | 901051088300 | BOLT FLANGE | ₹ 1075 | 1 | ||
| 9 | 902011084800 | WASHER, PLATE | ₹ 135 | 1 | ||
| 10A | B1X114160000 | PLANE BEARING, CRANKSHAFT 1 | ₹ 670 | 6 | BLUE | |
| 10B | B1X114161000 | PLANE BEARING, CRANKSHAFT 1 | ₹ 670 | 6 | BLACK | |
| 10C | B1X114162000 | PLANE BEARING, CRANKSHAFT 1 | ₹ 670 | 6 | BROWN | |
| 10D | B1X114163000 | PLANE BEARING, CRANKSHAFT 1 | ₹ 670 | 6 | GREEN | |
| 10E | B1X114164000 | PLANE BEARING, CRANKSHAFT 1 | ₹ 670 | 6 | YELLOW | |
| 11 | B2XE16310000 | PISTON (STD) | ₹ 3521 | 2 | ||
| 12 | BR5E16030000 | PISTON RING SET (STD) | ₹ 590 | 2 | ||
| 13 | 1WDE16330000 | PIN PISTON | ₹ 368 | 2 | ||
| 14 | 934501606800 | CIRCLIP | ₹ 50 | 4 | ||
| 15 | 1WDE15310000 | GEAR BALANCE WEIGHT | ₹ 1751 | 1 | ||
| 16 | 90105088F800 | BOLT FLANGE | ₹ 121 | 1 | ||
| 17 | 902820403600 | KEY STRAIGHT | ₹ 82 | 1 | ||
| 18 | 1WDE14960000 | BOSS BUFFER | ₹ 456 | 1 | ||
| 19 | 902011681200 | WASHER, PLATE | ₹ 55 | 1 | ||
| 20 | 905012280000 | SPRING COMPRESSION | ₹ 34 | 4 | ||
| 21 | 936051009000 | PIN, DOWEL | ₹ 48 | 2 | ||
| 22 | 1WDE14540000 | WEIGHT 1 | ₹ 3364 | 1 | ||
| 23A | 1WD114130000 | PLANE BEARING, BALANCE WEIGHT( | ₹ 180 | 4 | BLUE | |
| 23B | 1WD114131000 | PLANEBEARING,BALANCEWEIGHT(BLA | ₹ 180 | 4 | BLACK | |
| 23C | 1WD114132000 | PLANEBEARING,BALANCEWEIGHT(BRO | ₹ 180 | 4 | BROWN | |
| 23D | 1WD114133000 | PLANEBEARING,BALANCEWEIGHT(GRE | ₹ 180 | 4 | GREEN | |
| 23E | 1WD114134000 | PLANEBEARING,BALANCEWEIGHT(YEL | ₹ 285 | 4 | YELLOW |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - No description available
