DD41
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 21CE21560000 | SHAFT ROCKER 2 | ₹ 36 | 2 | ||
| 2 | 913120501600 | BOLT | ₹ 5 | 2 | ||
| 3 | BPDE21700000 | CAMSHAFT ASSY 1 | ₹ 1779 | 1 | ||
| 4 | 932100980900 | O-RING | ₹ 15 | 1 | ||
| 5 | 93306001YH00 | BEARING | ₹ 117 | 1 | ||
| 6 | BPDE22800000 | DECOMPRESSION ASSY | ₹ 350 | 1 | ||
| 7 | BPDE22880000 | CAM, DECOMPRESSION | ₹ 115 | 1 | ||
| 8 | BCWE21570000 | BOLT | ₹ 23 | 1 | ||
| 9 | BLVE111F0000 | PLATE | ₹ 59 | 1 | ||
| 10 | 950220601400 | BOLT FLANGE | ₹ 12 | 1 | ||
| 11 | 94568J909600 | CHAIN | ₹ 313 | 1 | ||
| 12 | BK7E22310000 | GUIDE STOPPER 1 | ₹ 28 | 1 | ||
| 13 | BK7E22410000 | GUIDE STOPPER 2 | ₹ 35 | 1 | ||
| 14 | 1GCE22280000 | BOLT | ₹ 19 | 1 | ||
| 15 | BK7E22560000 | COVER CHAIN | ₹ 14 | 1 | ||
| 16 | B7JE22100000 | TENSIONER ASSY CAM CHAIN | ₹ 175 | 1 | ||
| 17 | B0TE22130000 | GASKET TENSIONER CASE | ₹ 9 | 1 | ||
| 18 | BPDE54410000 | HOLDER, CLUTCH CABLE | ₹ 73 | 1 | ||
| 19 | 950220602500 | BOLT FLANGE | ₹ 11 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - This assembly controls the engine's timing. It features the Camshaft Assy, the Timing Chain, and the Cam Chain Tensioner. It also includes the decompression mechanism for easier starting and the rocker shafts. These parts must work in perfect synchronization to ensure the valves open and close at the exact right moment for peak engine performance.
