DD41
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BK7E85400000 | SHIFT CAM ASSY | ₹ 1474 | 1 | ||
| 2 | BK7E85420000 | POINT NEUTRAL | ₹ 10 | 1 | ||
| 3 | 905010602200 | SPRING COMPRESSION | ₹ 60 | 1 | ||
| 4 | B0TE85110000 | FORK, SHIFT 1 | ₹ 165 | 1 | ||
| 5 | B0TE85120000 | FORK, SHIFT 2 | ₹ 165 | 1 | ||
| 6 | B0TE85130000 | FORK, SHIFT 3 | ₹ 165 | 1 | ||
| 7 | 38BE85310000 | BAR SHIFT FORK GUIDE 1 | ₹ 42 | 1 | ||
| 8 | 905010680000 | SPRING COMPRESSION | ₹ 8 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Located inside the transmission, this assembly is responsible for selecting gears. It includes the Shift Cam Assy and the three Shift Forks that move the gears into position. The assembly also features the Shift Fork Guide Bars and the Neutral Point spring. These precision-machined parts are critical for smooth gear transitions and preventing false neutrals during spirited riding.
