HEAD LIGHT
21C4
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 21CH43001000 | HEADLIGHT ASSY | ₹ 1222 | 1 | ||
| 2 | 5TSH43140000 | BULB(12V-35W/35W-HALOGEN) | ₹ 150 | 1 | ||
| 3 | 21CH43470000 | BULB (12V-5W ) | ₹ 41 | 1 | ||
| 4 | 21CH45020000 | COVER COMP. | ₹ 41 | 1 | ||
| 5 | 21CH43120000 | HOLDER CORD ASSY | ₹ 42 | 1 | ||
| 6 | 904801410100 | GROMMET | ₹ 10 | 2 | ||
| 7 | 90387068D400 | COLLAR | ₹ 7 | 2 | ||
| 8 | 958020602500 | BOLT FLANGE | ₹ 6 | 2 | ||
| 9 | 901190611700 | BOLT WITH WASHER | ₹ 23 | 1 | ||
| 10 | 21CF31211033 | COVER UPPER 1-YB-21C2 | ₹ 145 | 1 | FOR BWC1 | |
| 11 | 977074001400 | SCREW, TAPPING | ₹ 3 | 3 | ||
| 12 | 21CF312210P2 | COVER OUTER 1-SILVER | ₹ 168 | 1 | FOR BWC1 | |
| 13 | 21CF313210P2 | COVER OUTER 2-SILVER | ₹ 168 | 1 | FOR BWC1 | |
| 14 | 21CH45270000 | DAMPER | ₹ 9 | 2 | ||
| 15 | 901110683000 | BOLT HEX. SOCKET BUTTON | ₹ 56 | 2 | ||
| 16 | 901110682900 | BOLT HEX. SOCKET BUTTON | ₹ 53 | 2 | ||
| 17 | 90387068E800 | COLLAR | ₹ 11 | 2 | ||
| 18 | 901830682100 | NUT SPRING | ₹ 23 | 4 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Piercing through the darkness requires a headlight assembly that is both powerful plus precisely aimed on your Yamaha FZS V1. This front facing illumination system is your primary defense against road hazards during late night journeys or misty mornings. The Headlight Assy is built to focus the beam exactly where you need it, illuminating the path ahead with clarity. Supporting this system, the Cover Comp plus Holder Cord Assy ensure that all internal wiring remains organized plus protected from the elements. The assembly is designed to resist the high heat generated by halogen bulbs while maintaining structural integrity over years of service. A clear lens plus reflective backing work together to amplify every watt of power, providing a broad field of vision. Choosing authentic Yamaha FZS V1 headlight components ensures that your beam pattern remains accurate, preventing glare for oncoming traffic while maximizing your own safety plus confidence on the road.
