SIDE COVER
21C5
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 21CXF17150P1 | SIDE COVER ASSY 1-MBL2 | ₹ 669 | 1 | ||
| 2 | 21CF172A00P1 | PANEL 1-MAT BLK-21C2 | ₹ 138 | 1 | ||
| 3 | 901830581800 | NUT SPRING | ₹ 9 | 2 | ||
| 4 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 2 | ||
| 5 | 21CXF17250P1 | SIDECOVERASSY2-MBL2(GREEN-SILV | ₹ 669 | 1 | ||
| 6 | 21CF172F00P1 | PANEL2-MAT BLK-21C2 | ₹ 138 | 1 | ||
| 7 | 901830581800 | NUT SPRING | ₹ 9 | 2 | ||
| 8 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 2 | ||
| 9 | 21CF17170000 | DAMPER | ₹ 2 | 2 | ||
| 10 | 5DGF17780000 | DAMPER LOCATING 1 | ₹ 2 | 2 | ||
| 11A | 21CXF1737033 | COVER SIDE 3-YB WITH DRMK GR | ₹ 428 | 1 | FOR DRMK | |
| 11B | 21CXF1736033 | COVER SIDE 3-YB WITH SILVER G | ₹ 428 | 1 | FOR YB | |
| 12A | 21CXF1748033 | 21CXF1748033 | ₹ 0 | 1 | FOR DRMK | |
| 12C | 21CXF1746033 | COVER SIDE 4-YB WITH SILVER G | ₹ 428 | 1 | FOR YB | |
| 13 | 901830581800 | NUT SPRING | ₹ 9 | 4 | ||
| 14 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 4 | ||
| 15 | 21CXF17C7033 | COVER SIDE 5 -FOR YB LGM6 | ₹ 352 | 1 | ||
| 16 | 5TSF836B0200 | TUNING FORK MARK | ₹ 23 | 1 | ||
| 17 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 4 | ||
| 18 | 985170601200 | SCREW PAN HEAD | ₹ 4 | 2 | ||
| 19 | 901190611400 | BOLT WITH WASHER | ₹ 15 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Protecting the internal components of the Yamaha FZ V1, the side panels define the clean aesthetic of this legendary motorcycle. This assembly includes the various covers that shield the battery, wiring from the Indian environment. Every panel is held securely by Nut spring plus truss head tapping screw units, ensuring a rattle free fitment. Beyond their visual role, these covers like the Side cover assy protect sensitive electronics from rain, dust. The integration of the Tuning fork mark adds a touch of premium branding. Durable materials resist the effects of heat, sunlight, preventing the plastic from cracking. Maintaining these covers is essential for the overall look, health of the street fighter. Every grommet, damper, bolt with washer contributes to a secure assembly that withstands the vibrations of daily riding. Experience the perfect combination of form, function in this bodywork, keeping the machine looking new while protecting its systems.
