HEAD LIGHT
0
21CA
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 21CH43001000 | HEADLIGHT ASSY | ₹ 1222 | 1 | ||
| 2 | 5TSH43140000 | BULB(12V-35W/35W-HALOGEN) | ₹ 150 | 1 | ||
| 3 | 21CH43470000 | BULB (12V-5W ) | ₹ 41 | 1 | ||
| 4 | 21CH45020000 | COVER COMP. | ₹ 41 | 1 | ||
| 5 | 21CH43120000 | HOLDER,CORD ASSY | ₹ 42 | 1 | ||
| 6 | 904801410100 | GROMMET | ₹ 10 | 2 | ||
| 7 | 90387068D400 | COLLAR | ₹ 8 | 2 | ||
| 8 | 958020602500 | BOLT FLANGE | ₹ 6 | 2 | ||
| 9 | 901190611700 | BOLT WITH WASHER | ₹ 23 | 1 | ||
| 10 | 21CF31211033 | COVER, UPPER 1-YB-21C2 | ₹ 158 | 1 | FOR YB | |
| 11 | 977074001400 | SCREW, TAPPING | ₹ 3 | 3 | ||
| 12 | 21CF31221033 | COVER, OUTER 1-YB-21C2 | ₹ 205 | 1 | FOR YB | |
| 13 | 21CF31321033 | COVER, OUTER 2- YB-21C2 | ₹ 160 | 1 | FOR YB | |
| 14 | 21CH45271000 | DAMPER | ₹ 6 | 2 | ||
| 15 | 901110683000 | BOLT,HEX. SOCKET BUTTON | ₹ 56 | 2 | ||
| 16 | 901110682900 | BOLT HEX. SOCKET BUTTON | ₹ 53 | 2 | ||
| 17 | 90387068E800 | COLLAR | ₹ 13 | 2 | ||
| 18 | 901830682100 | NUT SPRING | ₹ 23 | 4 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 21CA FZS V1 Series HEAD LIGHT
