FENDER
21CF
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 21CXF151D09X | FENDER FRONT-SILVER | ₹ 809 | 1 | FOR DPBML | |
| 2 | 904800880100 | GROMMET | ₹ 10 | 4 | ||
| 3 | 90387068C500 | COLLAR | ₹ 8 | 4 | ||
| 4 | 970220602000 | BOLT | ₹ 15 | 2 | ||
| 5 | 902010672600 | WASHER PLATE | ₹ 6 | 2 | ||
| 6 | 901110686800 | BOLT HEX. SOCKET BUTTON | ₹ 26 | 2 | ||
| 7 | 21CF16110100 | FENDER REAR | ₹ 483 | 1 | ||
| 8 | 21CF16510000 | COVER REAR FENDER | ₹ 48 | 1 | ||
| 9 | 970120601400 | BOLT | ₹ 5 | 4 | ||
| 10 | 903870604800 | COLLAR | ₹ 7 | 4 | ||
| 11 | 901830581800 | NUT SPRING | ₹ 9 | 2 | ||
| 12 | 21CF177G1000 | BOX BATTERY | ₹ 69 | 1 | ||
| 13 | 21CF17170000 | DAMPER | ₹ 2 | 1 | ||
| 14 | 4LSF47410000 | PAD SEAT | ₹ 8 | 1 | ||
| 15 | 901190611700 | BOLT WITH WASHER | ₹ 23 | 2 | ||
| 16 | 21CF16690000 | SEAL | ₹ 35 | 2 | ||
| 17 | 21CF16A20000 | SEAL 2 | ₹ 14 | 1 | ||
| 18 | 21CF16810000 | PLATE LICENSE | ₹ 41 | 1 | ||
| 19 | 901590602100 | SCREW WITH WASHER | ₹ 9 | 2 | ||
| 20 | 9530N0660000 | NUT | ₹ 1 | 2 | ||
| 21 | 902010607800 | WASHER PLATE | ₹ 10 | 2 | ||
| 22 | 21CF16210000 | FLAP | ₹ 142 | 1 | ||
| 23 | 977075001400 | SCREW TAPPING | ₹ 15 | 6 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Protection from road spray plus debris for your Yamaha FZS V1 is the primary job of this Fender assembly. The Fender front prevents water from splashing onto the engine, while the Fender rear shields the tail section plus the rider. This kit also includes the Box battery, providing a secure housing for the power cell. For legal compliance, the Plate license mount is integrated into the rear fender design. Every Collar plus Grommet ensures that the plastic parts are mounted with enough flexibility to resist cracking from road vibrations. The Flap provides additional protection for the rear suspension against mud plus stones. Indian riders facing monsoon conditions will appreciate the coverage provided by these genuine parts. Each Bolt plus Screw tapping is coated to prevent corrosion in humid environments. Maintain the cleanliness plus structural integrity of your motorcycle with these essential body components. Quality engineering ensures these fenders stay in place through every kilometer.
