HEAD LIGHT
21CF
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 21CH43001000 | HEADLIGHT ASSY | ₹ 1222 | 1 | ||
| 2 | 5TSH43140000 | BULB(12V-35W/35W-HALOGEN) | ₹ 150 | 1 | ||
| 3 | 21CH43470000 | BULB (12V-5W ) | ₹ 41 | 1 | ||
| 4 | 21CH45020000 | COVER COMP. | ₹ 41 | 1 | ||
| 5 | 21CH43120000 | HOLDER CORD ASSY | ₹ 42 | 1 | ||
| 6 | 904801410100 | GROMMET | ₹ 10 | 2 | ||
| 7 | 90387068D400 | COLLAR | ₹ 7 | 2 | ||
| 8 | 958020602500 | BOLT FLANGE | ₹ 6 | 2 | ||
| 9 | 901190611700 | BOLT WITH WASHER | ₹ 23 | 1 | ||
| 10 | 21CF31211033 | COVER UPPER 1-YB-21C2 | ₹ 145 | 1 | FOR DPBML | |
| 11 | 977074001400 | SCREW, TAPPING | ₹ 3 | 3 | ||
| 12 | 21CF312210P6 | COVER OUTER 1-DPBML | ₹ 194 | 1 | FOR DPBML | |
| 13 | 21CF313210P6 | COVER OUTER 2 -DPBML (PURPLE | ₹ 194 | 1 | FOR DPBML | |
| 14 | 21CH45271000 | DAMPER | ₹ 6 | 2 | ||
| 15 | 901110683000 | BOLT HEX. SOCKET BUTTON | ₹ 56 | 2 | ||
| 16 | 901110682900 | BOLT HEX. SOCKET BUTTON | ₹ 53 | 2 | ||
| 17 | 90387068E800 | COLLAR | ₹ 11 | 2 | ||
| 18 | 901830682100 | NUT SPRING | ₹ 23 | 4 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Illuminating the path ahead for your Yamaha FZS V1 becomes effortless with this Head Light assembly. This unit features a powerful Bulb halogen, slicing through darkness with a focused beam. The Headlight assy integrates perfectly with the aggressive street-fighter styling of your motorcycle. Protection for the internal optics comes from the Cover outer, finished in a striking premium hue. Precise fitment is guaranteed by the Collar plus Nut spring components included in this kit. Indian roads present various obstacles; therefore, a bright, reliable light source is indispensable for safe navigation. These genuine parts resist heat buildup, preventing the reflector from dulling over time. Each Bolt hex socket button provides a secure mount, minimizing lens shake on uneven surfaces. Maintaining your front lighting ensures you stay visible to oncoming traffic. Elevate your nighttime riding confidence with these premium quality components crafted for the legendary FZ line.
