HEAD LIGHT
21CK
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 21CH43001000 | HEADLIGHT ASSY | ₹ 1222 | 1 | ||
| 2 | 5TSH43140000 | BULB(12V-35W/35W-HALOGEN) | ₹ 150 | 1 | ||
| 3 | 21CH43470000 | BULB (12V-5W ) | ₹ 41 | 1 | ||
| 4 | 21CH45020000 | COVER COMP. | ₹ 41 | 1 | ||
| 5 | 21CH43120000 | HOLDER CORD ASSY | ₹ 42 | 1 | ||
| 6 | 904801410100 | GROMMET | ₹ 10 | 2 | ||
| 7 | 90387068D400 | COLLAR | ₹ 7 | 2 | ||
| 8 | 958020602500 | BOLT FLANGE | ₹ 6 | 2 | ||
| 9 | 901190611700 | BOLT WITH WASHER | ₹ 23 | 1 | ||
| 10 | 21CF31212000 | COVER UPPER 1 | ₹ 55 | 1 | ||
| 11 | 977074001400 | SCREW, TAPPING | ₹ 3 | 3 | ||
| 12A | 21CF31220033 | COVER OUTER1-YB | ₹ 145 | 1 | FOR YB | |
| 12B | 21CF312200P1 | COVER OUTER1-DRMK | ₹ 147 | 1 | FOR DRMK | |
| 12C | 21CF312200P3 | COVER OUTER 1-DPBML | ₹ 194 | 1 | FOR DPBML | |
| 13A | 21CF31320033 | COVER OUTER2-YB | ₹ 147 | 1 | FOR YB | |
| 13B | 21CF313200P1 | COVER OUTER2-DRMK | ₹ 142 | 1 | FOR DRMK | |
| 13C | 21CF313200P3 | COVER OUTER 2-DPBML | ₹ 194 | 1 | FOR DPBML | |
| 14 | 21CH45271000 | DAMPER | ₹ 6 | 4 | ||
| 15 | 901110612100 | BOLT HEX. SOCKET BUTTON | ₹ 63 | 4 | ||
| 16 | 901830682100 | NUT SPRING | ₹ 23 | 4 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Lighting your path with clarity is the main duty of the head light assembly on the Yamaha FZ V1. This powerful illumination unit delivers a focused halogen beam to pierce through the night plus foggy conditions common on Indian roads. The assembly includes a robust head light assy along with high quality bulbs for the main beam plus the pilot light. Housed within a stylish cover comp with dedicated aerodynamic outer covers; the light stays protected from road debris plus wind. Specialized collars plus bolt flange units ensure that the headlight remains securely aimed plus vibration free. By opting for this original lighting hardware; you ensure that your night vision is never compromised; providing a safer plus more enjoyable riding experience. The aggressive design perfectly complements the front profile of your motorcycle; making it visible plus identifiable during every hour of the day or night on any journey you take.
