FENDER
21CM
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 21CF1511000X | FENDER FRONT - YB | ₹ 797 | 1 | FOR YB | |
| 1B | 21CF1511001X | FENDER FRONT -DRMK (RED) | ₹ 1166 | 1 | FOR DRMK | |
| 2 | 90387068C500 | COLLAR | ₹ 8 | 4 | ||
| 3 | 904800880100 | GROMMET | ₹ 10 | 4 | ||
| 4 | 970220602000 | BOLT | ₹ 15 | 2 | ||
| 5 | 902010672600 | WASHER PLATE | ₹ 6 | 2 | ||
| 6 | 901110686800 | BOLT HEX. SOCKET BUTTON | ₹ 26 | 2 | ||
| 7 | 21CF16110100 | FENDER REAR | ₹ 483 | 1 | ||
| 8 | 21CF16510000 | COVER REAR FENDER | ₹ 48 | 1 | ||
| 9 | 970120601400 | BOLT | ₹ 5 | 4 | ||
| 10 | 903870604800 | COLLAR | ₹ 7 | 4 | ||
| 11 | 901830581800 | NUT SPRING | ₹ 9 | 2 | ||
| 12 | 21CF177G1000 | BOX BATTERY | ₹ 69 | 1 | ||
| 13 | 21CF17170000 | DAMPER | ₹ 2 | 1 | ||
| 14 | 4LSF47410000 | PAD SEAT | ₹ 8 | 1 | ||
| 15 | 901190611700 | BOLT WITH WASHER | ₹ 23 | 2 | ||
| 16 | 21CF16690000 | SEAL | ₹ 35 | 2 | ||
| 17 | 21CF16A20000 | SEAL 2 | ₹ 14 | 1 | ||
| 18 | 21CF16810000 | PLATE LICENSE | ₹ 41 | 1 | ||
| 19 | 901590602100 | SCREW WITH WASHER | ₹ 9 | 2 | ||
| 20 | 9530N0660000 | NUT | ₹ 1 | 2 | ||
| 21 | 902010607800 | WASHER PLATE | ₹ 10 | 2 | ||
| 22 | 21CF16210000 | FLAP | ₹ 142 | 1 | ||
| 23 | 977075001400 | SCREW TAPPING | ₹ 15 | 6 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Providing protection against the elements is the primary duty of the fender assembly on your Yamaha FZ V1. This hardware set features the front plus rear fenders designed to block mud; water; plus debris from splashing onto the engine plus rider. Crafted from impact resistant materials; these fenders are built to withstand the rigors of monsoon riding across India. The front fender features a sleek profile; while the rear fender includes a license plate stay plus a durable flap to maximize coverage. Secure fitment is ensured by specialized collar units plus grommets that isolate the panels from vibrations. Also included in this set is the battery box plus various pads to keep internal components protected plus silent. Every bolt plus washer plate is manufactured for corrosion resistance to ensure long term durability. Installing genuine factory fenders ensures that your motorcycle stays clean plus looking sharp; regardless of the road conditions you face every single day.
