SIDE COVER
2GS9
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2GSF17110000 | COVER SIDE 1 | ₹ 165 | 1 | ||
| 2 | 2GSF172A01P1 | PANEL 1 | ₹ 377 | 1 | FOR MBL2 | |
| 3 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 4 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 | ||
| 5 | 2GSF17210000 | COVER SIDE 2 | ₹ 198 | 1 | ||
| 6 | 2GSF172F01P1 | PANEL 2-MBL2 | ₹ 377 | 1 | FOR MBL2 | |
| 7 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 8 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 | ||
| 9 | 21CF17170000 | DAMPER | ₹ 2 | 2 | ||
| 10 | 2GSXF17390P4 | COVER SIDE 3 -MBL2(MAT BLACK) | ₹ 451 | 1 | FOR MBL2 | |
| 11 | 2GSXF17490P4 | COVER SIDE 4 -MBL2(MAT BLACK) | ₹ 451 | 1 | FOR MBL2 | |
| 12 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 13 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 | ||
| 14 | 902690681400 | RIVET | ₹ 8 | 2 | ||
| 15 | 2GSXF17C00P6 | COVER SIDE 5 - SMX(BLACK METAL | ₹ 267 | 1 | FOR MBL2 | |
| 16 | 5TSF836B0200 | TUNING FORK MARK | ₹ 23 | 1 | ||
| 17 | 902690681400 | RIVET | ₹ 8 | 2 | ||
| 18 | 901190613700 | BOLT WITH WASHER | ₹ 9 | 4 | ||
| 19 | 985070601400 | SCREW PAN HEAD | ₹ 9 | 2 | ||
| 20 | 902010605500 | WASHER PLATE | ₹ 3 | 2 | ||
| 21 | 904800155800 | GROMMET | ₹ 10 | 2 | ||
| 22 | 2GSF171L0000 | MOLE SIDE COVER 1 | ₹ 23 | 1 | ||
| 23 | 2GSF171M0000 | MOLE SIDE COVER 2 | ₹ 23 | 1 | ||
| 24 | 901830506700 | NUT SPRING | ₹ 8 | 2 | ||
| 25 | 2GSF17320000 | SEAL 1 | ₹ 2 | 1 | ||
| 26 | 2GSF17350000 | SEAL 2 | ₹ 2 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The visual flow of your Yamaha FZS V2 is completed by the side cover assembly, which protects the sensitive electrical plus internal components from the environment. These panels, including the Cover Side plus Panel units, are crafted from high-impact polymers designed to withstand the heat plus vibration of daily street riding. Secured by a network of Nut Spring plus specialized rivets, these covers provide a tight plus rattle-free fit that maintains the bike's premium feel. The Tuning Fork Mark on the exterior is a symbol of the precision engineering found throughout the machine. Small details like the Mole Side Cover plus various seals ensure that moisture plus dust stay away from the battery plus airbox during the monsoon. Choosing authentic Yamaha FZS V2 side panels ensures that the colors match perfectly plus the gaps remain tight, keeping your motorcycle looking as sharp plus modern as the day it first rolled out of the showroom, preserved for the long term through every season.
