HEADLIGHT
0
2GSD
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2GSH43001000 | HEADLIGHT ASSY | ₹ 1275 | 1 | ||
| 2 | 2GSH430A1000 | HEADLIGHT UNIT ASS | ₹ 810 | 1 | ||
| 3 | 5TSH43140000 | BULB(12V-35W/35W-HALOGEN) | ₹ 150 | 1 | ||
| 4 | 2LPH43470000 | BULB ( 12V-5W ) | ₹ 23 | 1 | ||
| 5 | B62H43350000 | SPRING | ₹ 7 | 1 | ||
| 6 | 2LPH45260000 | SCREW | ₹ 3 | 1 | ||
| 7 | 2GSH45020000 | COVER COMP. | ₹ 60 | 1 | ||
| 8 | 977074051200 | SCREW, TAPPING | ₹ 4 | 2 | ||
| 9 | 2GSH43181000 | STAY HEADLIGHT 1 | ₹ 31 | 1 | ||
| 10 | 2GSH43120000 | CORD ASSY | ₹ 42 | 1 | ||
| 11 | 904801410100 | GROMMET | ₹ 10 | 2 | ||
| 12 | 90387068D400 | COLLAR | ₹ 8 | 2 | ||
| 13 | 958020602500 | BOLT FLANGE | ₹ 6 | 2 | ||
| 14 | 958120601200 | BOLT, FLANGE | ₹ 3 | 1 | ||
| 15 | 901830606900 | NUT SPRING | ₹ 159 | 3 | ||
| 16 | 2GSF31210000 | COVER UPPER 1 | ₹ 70 | 1 | ||
| 17 | 902690681400 | RIVET | ₹ 8 | 3 | ||
| 18 | 2GSXF31250P3 | COVER OUTER 1 -SMX(BLACK META | ₹ 265 | 1 | FOR MBL2 | |
| 19 | 2GSF83915000 | GRAPHIC 1 | ₹ 172 | 1 | ||
| 20 | 2GSXF31350P3 | COVER OUTER 2 -SMX(BLACK META | ₹ 265 | 1 | FOR MBL2 | |
| 21 | 2GSF83925000 | GRAPHIC 2 | ₹ 172 | 1 | ||
| 22 | 901600581200 | SCREW ROUND TAPPING | ₹ 10 | 2 | ||
| 23 | 2GSF312300P0 | COVER UNDER 1 - MBL2 (MAT BLA | ₹ 315 | 1 | FOR MBL2 | |
| 24 | 902690681400 | RIVET | ₹ 8 | 4 | ||
| 25 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 26 | 901830580700 | NUT SPRING | ₹ 9 | 3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 2GSD FZS V2 Series HEADLIGHT
