HEAD LIGHT
2LP6
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 2LPWF8350033 | BODY COWLING ASSY 1 YB ( BLACK | ₹ 783 | 1 | FOR YB | |
| 1B | 2LPWF83500P1 | BODY COWLING SUB ASSY.-DBNM8(G | ₹ 783 | 1 | FOR DBNM8 | |
| 1C | 2LPWF83500P2 | BODY COWLING SUB ASSY.-BWC1(WH | ₹ 783 | 1 | FOR BWC1 | |
| 1D | 2LPWF83500P3 | BODYCOWLINGSUB ASSY-DPMBL(PURP | ₹ 783 | 1 | FOR DPBML | |
| 2 | 2LPF83810000 | WINDSHIELD | ₹ 115 | 1 | ||
| 3 | 5TSF836B0200 | TUNING FORK MARK | ₹ 23 | 1 | ||
| 4 | 5TSF81870000 | GROMMET | ₹ 5 | 4 | ||
| 5 | 5TSF83870000 | RIVET | ₹ 4 | 4 | ||
| 6 | 901830506700 | NUT SPRING | ₹ 8 | 4 | ||
| 7 | 904801339800 | GROMMET | ₹ 10 | 1 | ||
| 8 | 901830581400 | NUT SPRING | ₹ 14 | 2 | ||
| 9 | 2LPH43100000 | HEADLIGHT UNIT ASSY | ₹ 945 | 1 | ||
| 10 | 2LPH430A0000 | HEADLIGHT UNIT ASSY | ₹ 590 | 1 | ||
| 11 | 2LPH43350000 | SPRING | ₹ 8 | 1 | ||
| 12 | 2LPH45260000 | SCREW | ₹ 3 | 1 | ||
| 13 | 2LPH45020000 | COVER COMP. | ₹ 56 | 1 | ||
| 14 | 2LPH43140000 | BULB HEADLIGHT 12V-35/35W | ₹ 140 | 1 | ||
| 15 | 2LPH43470000 | BULB ( 12V-5W ) | ₹ 23 | 1 | ||
| 16 | 2LPH43120000 | CORD ASSY | ₹ 37 | 1 | ||
| 17 | 2LPH43170000 | NUT | ₹ 7 | 1 | ||
| 18 | 2LPH43740000 | CLIP | ₹ 9 | 2 | ||
| 19 | 958270601400 | BOLT FLANGE | ₹ 18 | 1 | ||
| 20 | 2LPF34870000 | STAY PLATE | ₹ 24 | 1 | ||
| 21 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 | ||
| 22 | 905201082700 | DAMPER PLATE | ₹ 9 | 2 | ||
| 23 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 24 | 901050536100 | BOLT FLANGE | ₹ 10 | 2 | ||
| 25 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The front profile of your Yamaha Saluto Disc is anchored by its efficient headlight assembly, which offers clear illumination for all your daily journeys. This specialized catalog provides the essential components needed to maintain your visibility and the professional look of your machine during night rides. At the center is the Headlight Unit Assy, supported by the protective Body Cowling Assy and the durable Windshield, which are all engineered for maximum longevity. These parts are designed to withstand high speed vibrations and road debris, ensuring that your beam remains stable and clear in all conditions. Every Nut Spring and Screw Tapping is manufactured to precise tolerances, providing a secure and rattle free installation that matches factory specifications perfectly. By selecting genuine lighting hardware, you preserve the safety and functional appeal of your motorcycle. Trust in original Yamaha parts to keep your adventures bright and your motorcycle looking sharp today.
