STEERING HANDLE & CABLE
2VB1/2FC1
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2SPF61100000 | HANDLE COMP. | ₹ 742 | 1 | ||
| 2 | 901051028300 | BOLT FLANGE | ₹ 24 | 1 | ||
| 3 | 956021020000 | NUT U FLANGE | ₹ 32 | 1 | ||
| 4 | 977025001600 | SCREW TAPPING | ₹ 10 | 3 | ||
| 5A | 2FCF61430033 | COVER HANDLE UPPER-YB(BLACK) | ₹ 519 | 1 | FOR YB | |
| 5B | 2FCF614300P0 | COVER HANDLE UPPER-DBNM8(GRAY | ₹ 519 | 1 | FOR DBNM8 | |
| 5C | 2FCF614300P1 | COVER HANDLE UPPE R-BWC1-(WHI | ₹ 519 | 1 | FOR BWC1 | |
| 5D | 2FCF614300P2 | COVER HANDLE UPPER-VRC1(VIVID | ₹ 519 | 1 | FOR VRC1 | |
| 5E | 2FCF614300P3 | COVER HANDLE UPPER-DPRMG(PURP | ₹ 519 | 1 | FOR DPRMG | |
| 6 | 977025001600 | SCREW TAPPING | ₹ 10 | 2 | ||
| 7 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 8 | 2FCF61450000 | COVER HANDLE UPPER | ₹ 165 | 1 | ||
| 9 | 977025001600 | SCREW TAPPING | ₹ 10 | 4 | ||
| 10 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 11A | 2FCH35590133 | COVER METER -YB(YAMAHA BLACK) | ₹ 258 | 1 | FOR YB | |
| 11B | 2FCH355901P0 | COVER METER-DBNM8(GRAY | ₹ 258 | 1 | FOR DBNM8 | |
| 11C | 2FCH355901P1 | COVER METER -BWC1(WHITE) | ₹ 258 | 1 | FOR BWC1 | |
| 11D | 2FCH355901P2 | COVER METER-VRC1(VIVID RED) | ₹ 258 | 1 | FOR VRC1 | |
| 11E | 2FCH355901P3 | COVER METER-DPRMG(PURPLE RED) | ₹ 299 | 1 | FOR DPRMG | |
| 12 | 2FSF62400000 | GRIP ASSY | ₹ 40 | 1 | ||
| 13 | 2FSF62810000 | CAP GRIP UPPER | ₹ 13 | 1 | ||
| 14 | 2FSF62820000 | CAP GRIP UNDER | ₹ 13 | 1 | ||
| 15 | 985020502500 | SCREW PAN HEAD | ₹ 4 | 2 | ||
| 16 | 54BF62410000 | GRIP | ₹ 35 | 1 | ||
| 17 | 2FCF62800000 | REAR VIEW MIRROR ASSY 1-LH | ₹ 178 | 1 | ||
| 18 | 2FCF62900000 | REAR VIEW MIRROR ASSY 1-RH | ₹ 178 | 1 | ||
| 19 | 2FSF63110000 | CABLE THROTTLE 1 | ₹ 299 | 1 | ||
| 20 | 985020502000 | SCREW PAN HEAD | ₹ 4 | 1 | ||
| 21 | 904642480200 | CLAMP | ₹ 13 | 1 | ||
| 22 | 1GCF63410000 | CABLE BRAKE | ₹ 188 | 1 | ||
| 23 | 905011080900 | SPRING COMPRESSION | ₹ 6 | 1 | ||
| 24 | 901790680600 | NUT BRAKE | ₹ 17 | 1 | ||
| 25 | 902491200800 | PIN | ₹ 20 | 1 | ||
| 26 | 1GCF63510100 | CABLE BRAKE | ₹ 377 | 1 | ||
| 27 | 905011680400 | SPRING COMPRESSION | ₹ 10 | 1 | ||
| 28 | 901790680600 | NUT BRAKE | ₹ 17 | 1 | ||
| 29 | 902491200800 | PIN | ₹ 20 | 1 | ||
| 30 | 1GCF637G0000 | HOLDER WIRE | ₹ 16 | 1 | ||
| 31 | 1GCF62570000 | STOPPER | ₹ 5 | 1 | ||
| 32 | 950220604000 | BOLT FLANGE | ₹ 18 | 1 | ||
| 33 | 950220601000 | BOLT FLANGE | ₹ 15 | 1 | ||
| 34 | 2FSF63310000 | CABLE STARTER 1 | ₹ 170 | 1 | ||
| 35 | 1GCF63530000 | NUT ADJUSTING | ₹ 15 | 1 | ||
| 36 | 2FSF62790000 | GUIDE CABLE | ₹ 23 | 1 | ||
| 37 | 950220601200 | BOLT FLANGE | ₹ 8 | 2 | ||
| 38 | 2FSF637G0000 | HOLDER WIRE | ₹ 13 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Achieving the perfect balance between comfort and control starts with your handlebars, and our steering and handle cable assembly for the Yamaha Alpha is designed to deliver precisely that. A smooth ride depends on responsive controls, which is why our catalog includes high quality parts that ensure effortless maneuvering. Whether you are navigating tight corners or holding a steady line on the road, we provide the essential hardware like the Handle Comp, smooth Cable Throttle, and durable Cable Brake. These cables are engineered for longevity and smooth action, minimizing resistance during your daily commute. Investing in quality steering components ensures that your scooter responds immediately to your touch, enhancing both safety and rider satisfaction. Browse our complete inventory to find the cables and grips required to upgrade your handling experience. Restore your machine to its original agile state with our premium selection of steering components.
