ELECTRICAL 1
0
2YS3
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 1WDH23100000 | IGNITION COIL ASSY | ₹ 410 | 2 | ||
| 2 | B04H23140000 | B04H23140000 | ₹ 0 | 1 | ||
| 3 | B04H23141000 | B04H23141000 | ₹ 0 | 1 | ||
| 4 | 950220602000 | BOLT FLANGE | ₹ 15 | 2 | ||
| 5 | 1WDH23700000 | PLUG CAP ASSY | ₹ 1380 | 2 | ||
| 6 | 1WDH21000100 | BATTERY ASSY | ₹ 0 | 1 | ||
| 7 | 1WDH21210000 | PAD, BATTERY | ₹ 195 | 1 | ||
| 8 | 1WDH21310000 | BAND, BATTERY | ₹ 80 | 1 | ||
| 9 | 2WDH25901000 | WIRE HARNESS ASSY | ₹ 13620 | 1 | ||
| 10 | 1WDH21512000 | FUSE | ₹ 42 | 4 | ||
| 11 | 1WDH21511000 | FUSE | ₹ 42 | 4 | ||
| 12 | 4WA819800000 | DIODE ASSY | ₹ 395 | 1 | ||
| 13 | 3WP819800000 | DIODE ASSY | ₹ 270 | 2 | ||
| 14 | 1WDH21513000 | 1WDH21513000 | ₹ 0 | 2 | ||
| 15 | 1WDH19500000 | RELAY ASSY | ₹ 270 | 4 | ||
| 16 | 1WDH19400000 | STARTER RELAY ASSY | ₹ 400 | 1 | ||
| 17 | 1WDH21510100 | FUSE | ₹ 17 | 2 | ||
| 18 | 913120500800 | BOLT | ₹ 31 | 2 | ||
| 19 | 2WDH21150000 | WIRE, PLUS LEAD | ₹ 264 | 1 | ||
| 20 | 2WDH21160000 | WIRE, MINUS LEAD | ₹ 477 | 1 | ||
| 21 | 904643680000 | CLAMP | ₹ 8 | 2 | ||
| 22 | 904647080000 | CLAMP | ₹ 14 | 7 | ||
| 23 | 904642280000 | CLAMP | ₹ 9 | 1 | ||
| 24 | 904645080000 | CLAMP | ₹ 6 | 1 | ||
| 25 | 1WDH25010200 | MAIN SWITCH STEERING LOCK | ₹ 2049 | 1 | ||
| 26 | 901090628200 | BOLT | ₹ 80 | 2 | ||
| 27 | 1WDXH2500000 | 1WDXH2500000 | ₹ 0 | 1 | ||
| 28 | 1WDF179E0000 | BAND | ₹ 320 | 1 | ||
| 29 | 1WDH25910000 | 1WDH25910000 | ₹ 0 | 1 | ||
| 30 | 904642600100 | CLAMP | ₹ 35 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 2YS3 R3 Series ELECTRICAL 1
