ELECTRICAL 3
2YS3
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2WD859300800 | HYDRAULIC UNIT ASSY | ₹ 56144 | 1 | ||
| 2 | 2WDF175T0000 | BRACKET 1 | ₹ 861 | 1 | ||
| 3 | 950220601000 | BOLT FLANGE | ₹ 15 | 3 | ||
| 4 | 950220602500 | BOLT FLANGE | ₹ 11 | 3 | ||
| 5 | 9038706M6000 | COLLAR | ₹ 196 | 3 | ||
| 6 | 904801422900 | GROMMET | ₹ 9 | 3 | ||
| 7 | 2WDF58860000 | HOLDER BRAKE HOSE | ₹ 94 | 1 | ||
| 8 | 950220601200 | BOLT FLANGE | ₹ 8 | 1 | ||
| 9 | 2WDF58750000 | HOLDER BRAKE HOSE 1 | ₹ 159 | 1 | ||
| 10 | 950220601200 | BOLT FLANGE | ₹ 8 | 2 | ||
| 11 | 2WD859700100 | WHEEL SENSOR ASSY FRONT | ₹ 7400 | 1 | ||
| 12 | 904642280000 | CLAMP | ₹ 9 | 1 | ||
| 13 | 950270601600 | BOLT FLANGE | ₹ 5 | 1 | ||
| 14 | 904641201300 | CLAMP | ₹ 120 | 3 | ||
| 15 | 2WDF33180000 | HOLDER CABLE 1 | ₹ 148 | 1 | ||
| 16 | 2WDF33190000 | HOLDER CABLE 2 | ₹ 342 | 1 | ||
| 17 | 901100681000 | BOLT HEX SOCKET HD | ₹ 13 | 1 | ||
| 18 | 2WD859800100 | WHEEL SENSOR ASSY REAR | ₹ 5801 | 1 | ||
| 19 | 920120601600 | BOLT BUTTON HEAD | ₹ 14 | 1 | ||
| 20 | 904641480300 | CLAMP | ₹ 14 | 1 | ||
| 21 | 904641080000 | CLAMP | ₹ 127 | 1 | ||
| 22 | 904641480300 | CLAMP | ₹ 14 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Every day passionate riders of the legendary Yamaha R3 motorcycle seek out the finest original electrical components to maintain the unmatched performance of their cherished machine. In the heart of India where the open roads beckon every thrill seeker ensuring your bike runs flawlessly is a tale of true dedication. Our carefully curated selection of authentic parts offers everything a discerning owner needs for total peace of mind. Dive deep into our vast inventory and discover essential items such as the precision engineered hydraulic unit assembly and the highly responsive front wheel sensor assembly. These critical pieces work harmoniously to keep your ride smooth and safe under any demanding conditions. Whether you are replacing a worn out component or upgrading for a long journey trust in our reliable catalog to preserve the soul of your motorcycle with absolute perfection.
