GENERATOR
0
2YS3
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 1WDH14500000 | ROTOR ASSY | ₹ 4290 | 1 | ||
| 2 | 1WDH14100100 | STATOR ASSY | ₹ 4950 | 1 | ||
| 3 | 913170603000 | BOLT | ₹ 15 | 3 | ||
| 4 | 901051088300 | BOLT, FLANGE | ₹ 1075 | 1 | ||
| 5 | 90201105A200 | WASHER, PLATE | ₹ 70 | 1 | ||
| 6 | 902800500100 | KEY WOODRUFF | ₹ 282 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 2YS3 R3 Series GENERATOR
