FENDER
0
35B3
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 35BF151000P3 | FRONT FENDER COMP-DPBMY | ₹ 1303 | 1 | ||
| 2 | 958070602000 | BOLT FLANGE | ₹ 5 | 4 | ||
| 3 | 5TSF15180100 | HOLDER, CABLE | ₹ 25 | 1 | ||
| 4 | 35BF16000000 | REAR FENDER ASSY.(WITH FLAP) | ₹ 410 | 1 | ||
| 5 | 5YYF16910000 | FLAP REAR FENDER | ₹ 11 | 1 | ||
| 6 | 9850N0501200 | SCREW PAN HEAD | ₹ 2 | 2 | ||
| 7 | 902010572500 | WASHER PLAIN | ₹ 40 | 4 | ||
| 8 | 9530N0560000 | NUT HEX | ₹ 2 | 2 | ||
| 9 | 901190610800 | BOLT WITH WASHER | ₹ 6 | 3 | ||
| 10 | 904641082900 | CLAMP | ₹ 6 | 1 | ||
| 11 | 21CF16810000 | PLATE LICENSE | ₹ 45 | 1 | ||
| 12 | 929070660000 | WASHER | ₹ 5 | 2 | ||
| 13 | 901590602100 | SCREW WITH WASHER | ₹ 9 | 2 | ||
| 14 | 9530N0660000 | NUT | ₹ 1 | 2 | ||
| 15 | 5USH51100100 | REFLECTOR ASSY | ₹ 16 | 1 | ||
| 16 | 957070550000 | NUT FLANGE | ₹ 1 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 35B3 GLADIATOR 125 SS Series FENDER
