FRONT WHEEL
0
38B2
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 38BXF51640P0 | 38BXF51640P0 | ₹ 0 | 1 | FOR BWC1 | |
| 2 | 20PF510C0000 | COLLAR ASSY. | ₹ 35 | 1 | ||
| 3 | 93306301XN00 | BEARING | ₹ 170 | 1 | ||
| 4 | 931062082300 | OIL SEAL | ₹ 24 | 1 | ||
| 5 | 93306201X800 | BEARING | ₹ 144 | 1 | ||
| 6 | 941081783100 | 941081783100 | ₹ 0 | 1 | ||
| 7 | 939000082400 | VALVE RIM | ₹ 19 | 1 | ||
| 8A | 5MT253980000 | BALANCER, WHEEL | ₹ 150 | 1 | ||
| 8B | 5MT253981000 | BALANCER, WHEEL(10G) | ₹ 160 | 1 | ||
| 8C | 5MT253982000 | BALANCER, WHEEL(30G) | ₹ 170 | 1 | ||
| 9 | 20PF51860000 | COLLAR WHEEL | ₹ 63 | 1 | ||
| 10 | 20PF51810000 | 20PF51810000 | ₹ 0 | 1 | ||
| 11 | 956071220000 | NUT U | ₹ 116 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 38B2 R15 V1 Series FRONT WHEEL
