FENDER
5TSF
.jpg)
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 5TSF1510610X | 5TSF1510610X | ₹ 0 | 1 | FOR DRMK | |
| 1B | 5TSF1510611X | FRONT FENDER COMP.YAMAHA BLACK | ₹ 885 | 1 | FOR YB,YB1 | |
| 2 | 958270601600 | BOLT FLANGE | ₹ 5 | 4 | ||
| 3 | 5TSF15180100 | HOLDER, CABLE | ₹ 23 | 1 | ||
| 4 | 5TSF16202000 | MUD GUARD COMP 5TSF/5TSG | ₹ 271 | 1 | ||
| 5 | 5TSF16911100 | FLAP | ₹ 12 | 1 | ||
| 6 | 9530N0560000 | NUT HEX | ₹ 2 | 2 | ||
| 7 | 902010572500 | WASHER PLAIN | ₹ 40 | 4 | ||
| 8 | 9850N0501200 | SCREW PAN HEAD | ₹ 2 | 2 | ||
| 9 | 901190610800 | BOLT WITH WASHER | ₹ 6 | 3 | ||
| 10 | 5TSF16850000 | BRACKET LICENCE | ₹ 60 | 1 | ||
| 11 | 901190610800 | BOLT WITH WASHER | ₹ 6 | 2 | ||
| 12 | 904641082900 | CLAMP | ₹ 6 | 3 | ||
| 13 | 5TSF16210100 | FLAP | ₹ 80 | 1 | ||
| 14 | 21CF16810000 | PLATE LICENSE | ₹ 41 | 1 | ||
| 15 | 985170601200 | SCREW PAN HEAD | ₹ 4 | 2 | ||
| 16 | 9290N0610000 | WASHER, SPRING | ₹ 1 | 2 | ||
| 17 | 5USH51100100 | REFLECTOR ASSY | ₹ 14 | 1 | ||
| 18 | 902010572500 | WASHER PLAIN | ₹ 40 | 1 | ||
| 19 | 957070550000 | NUT FLANGE | ₹ 1 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Protecting the rider and the motorcycle from road spray is the vital task of the Yamaha YBR mudguards and plates. As you travel through the dusty or wet conditions of India, the Front Fender Comp and the Rear Fender provide essential coverage. This assembly includes technical items such as the Mud Guard and various clamps that hold the fenders and cables in place. The catalog also features the license plate brackets and reflectors required for vehicle legality and visibility. Sturdy bolts and washers ensure that these components remain firmly attached despite constant wind pressure and vibrations. High quality plastics and metals are used to ensure these parts do not warp or corrode over time. Whether you are navigating city traffic or rural paths, these genuine fenders keep your motorcycle cleaner and protect your engine from flying debris. Ensure your bike stays looking sharp and remains road legal with these original replacement components.
