HEAD LIGHT
5TSF
.jpg)
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 5TSWF83570P0 | PANEL COMP. 1-DRMK | ₹ 1591 | 1 | FOR DRMK | |
| 1B | 5TSWF8358033 | COWLING ASSY - YB(PANEL COMP) | ₹ 1591 | 1 | FOR YB,YB1 | |
| 2A | 5TSF835120P0 | BODY COWLING-DRMK-5TSA B | ₹ 663 | 1 | FOR DRMK | |
| 2B | 5TSF83513033 | BODY COWLING - YB | ₹ 312 | 1 | FOR YB,YB1 | |
| 3 | 5TSF83812000 | WINDOW FRONT - 5TSA B F | ₹ 217 | 1 | ||
| 4 | 5TSF83870000 | RIVET | ₹ 4 | 6 | ||
| 5 | 5TSF81870000 | GROMMET | ₹ 5 | 6 | ||
| 6 | 901830506700 | NUT SPRING | ₹ 8 | 6 | ||
| 7 | 5TSF836B0200 | TUNING FORK MARK | ₹ 23 | 1 | ||
| 8 | 5TSF83362000 | PLATE | ₹ 55 | 1 | ||
| 9 | 958070601200 | BOLT FLANGE | ₹ 8 | 2 | ||
| 10 | 5TSH43102000 | HEADLIGHT UNIT ASSY | ₹ 907 | 1 | ||
| 11 | 5TSH43140000 | BULB(12V-35W/35W-HALOGEN) | ₹ 150 | 1 | ||
| 12 | 977074001400 | SCREW, TAPPING | ₹ 3 | 8 | ||
| 13 | 5YYH43660000 | DAMPER HEADLIGHT 1 | ₹ 27 | 2 | ||
| 14 | 901100610200 | BOLT, HEXAGON SOCKET HEAD | ₹ 39 | 2 | ||
| 15 | 902020617000 | WASHER PLAIN | ₹ 1 | 2 | ||
| 16 | 902020980100 | WASHER PLATE | ₹ 4 | 2 | ||
| 17 | 958070601200 | BOLT FLANGE | ₹ 8 | 1 | ||
| 18 | 5TSF836K0000 | PANEL INNER 1 | ₹ 10 | 1 | ||
| 19 | 5TSF836L0000 | PANEL INNER 2 | ₹ 10 | 1 | ||
| 20 | 901540505100 | SCREW CROSS REC. | ₹ 2 | 2 | ||
| 21 | 902010808500 | WASHER PLAIN | ₹ 1 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Piercing through the darkness of the Indian landscape requires a powerful front lighting system. The Yamaha YBR front lighting assembly is more than just a lamp; it is a sophisticated cowling system that protects your path. This catalog features the Headlight Unit Assy and the specific halogen bulb designed for optimal beam spread. Technical details like the Body Cowling and the inner panels provide the structural integrity needed to withstand wind pressure and debris. Components such as the Grommet and various spring nuts ensure a rattle free fitment of the entire front fascia. Maintaining the window front and the tuning fork mark keeps your motorcycle looking pristine while performing at its peak. Every bolt flange and tapping screw is engineered to hold the assembly securely against the rigors of high speed travel. Restore the original brilliance and aesthetic of your bike with these genuine components tailored for the perfect fit.
