SEAT
0
5TSG
.jpg)
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 5TSF47302000 | DOUBLE SEAT ASSY | ₹ 1275 | 1 | ||
| 2 | 4LSF47410000 | PAD SEAT | ₹ 8 | 6 | ||
| 3 | 901190610800 | BOLT WITH WASHER | ₹ 6 | 2 | ||
| 4A | 5TSXF471M033 | COVER, TAIL 1- YB | ₹ 424 | 1 | FOR DRMK | |
| 4B | 5TSXF471N033 | COVER, TAIL 1- YB | ₹ 424 | 1 | FOR YB | |
| 4C | 5TSXF471P0P0 | COVER, TAIL 1- DRMK | ₹ 422 | 1 | FOR YB1 | |
| 5A | 5TSXF472M033 | COVER, TAIL 2-DRMK | ₹ 424 | 1 | FOR DRMK | |
| 5B | 5TSXF472N033 | COVER, TAIL 2-YB | ₹ 424 | 1 | FOR YB | |
| 5C | 5TSXF472P0P0 | COVER, TAIL 2-DRMK | ₹ 422 | 1 | FOR YB1 | |
| 6A | 5TSXF4754033 | COVER, TAIL - YB (BLACK) FOR D | ₹ 230 | 1 | FOR DRMK,YB | |
| 6B | 5TSXF47550P0 | COVER, TAIL -DRMK (RED) | ₹ 230 | 1 | FOR YB1 | |
| 7 | 977025001200 | SCREW TAPPING | ₹ 11 | 4 | ||
| 8 | 5TSF834E0000 | DAMPER 1 | ₹ 8 | 1 | ||
| 9 | 901190613700 | BOLT WITH WASHER | ₹ 9 | 4 | ||
| 10 | 904800187000 | GROMMET | ₹ 6 | 2 | ||
| 11 | 5TSXF4775000 | HANDLE SEAT SUB ASSY | ₹ 757 | 1 | ||
| 12 | 958170802000 | BOLT FLANGE | ₹ 8 | 4 | ||
| 13 | 5TSF44810000 | PLUG | ₹ 3 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 5TSG YBR 110 Series SEAT
