FENDER
0
5US1
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 5USF151100H6 | 5USF151100H6 | ₹ 0 | 1 | FOR CNM | |
| 1B | 5USF151020P0 | FRONT FENDER COMP. (LYNM9) | ₹ 705 | 1 | FOR LYNM9 | |
| 1C | 5USF151100H9 | 5USF151100H9 | ₹ 0 | 1 | FOR BG | |
| 2 | 5KAF15180000 | HOLDER WIRE | ₹ 6 | 1 | ||
| 3 | 5USF84570000 | CLIP | ₹ 3 | 4 | ||
| 4 | 5USF16110000 | REAR FENDER | ₹ 113 | 1 | ||
| 5 | 901190610800 | BOLT WITH WASHER | ₹ 6 | 4 | ||
| 6 | 901830581800 | NUT SPRING | ₹ 9 | 2 | ||
| 7 | 5USF16390000 | DAMPER | ₹ 2 | 1 | ||
| 8A | 5USF163A10H6 | TAIL COVER 1-LEFT- (CNM) | ₹ 506 | 1 | FOR CNM | |
| 8B | 5USF163A20P0 | COVER 1 (LYNM9) | ₹ 460 | 1 | FOR LYNM9 | |
| 8C | 5USF163A00H9 | COVER 1 (YB) | ₹ 460 | 1 | FOR BG | |
| 9 | 901590617800 | SCREW W/WASHER | ₹ 3 | 1 | ||
| 10 | 901600580600 | SCREW TRUSS HD.TAP | ₹ 2 | 2 | ||
| 11 | 5USF171L0000 | MOLE SIDE COVER 1 | ₹ 130 | 1 | ||
| 12 | 5USF173T0000 | TAPE-1 | ₹ 5 | 3 | ||
| 13A | 5USF163E10H6 | COVER 2 -RIGHT-(CNM) | ₹ 506 | 2 | FOR CNM | |
| 13B | 5USF163E20P0 | COVER 2 (LYNM9) | ₹ 460 | 1 | FOR LYNM9 | |
| 13C | 5USF163E00H9 | COVER 2 (BG) | ₹ 460 | 1 | FOR BG | |
| 14 | 901590617800 | SCREW W/WASHER | ₹ 3 | 1 | ||
| 15 | 901600580600 | SCREW TRUSS HD.TAP | ₹ 2 | 2 | ||
| 16 | 5USF171M0000 | MOLE SIDE COVER 2 | ₹ 130 | 1 | ||
| 17 | 5USF173T0000 | TAPE-1 | ₹ 5 | 3 | ||
| 18A | 5USF163F00H6 | COVER REAR FENDER 3 -CNM | ₹ 506 | 1 | FOR CNM | |
| 18B | 5USF163F00P0 | COVER TAIL ASSY 3 (LYNM9) | ₹ 460 | 1 | FOR LYNM9 | |
| 18C | 5USF163F00H9 | COVER TAIL ASSY 3 (BG) | ₹ 460 | 1 | FOR BG | |
| 19A | 5USF172A10H6 | PANEL 1 (CNM) | ₹ 42 | 1 | FOR CNM | |
| 19B | 5USF172A20P0 | PANEL 1 (LYNM9) | ₹ 38 | 1 | FOR LYNM9 | |
| 19C | 5USF172A00H9 | PANEL 1 (BG) | ₹ 30 | 1 | FOR BG | |
| 20 | 901590617800 | SCREW W/WASHER | ₹ 3 | 1 | ||
| 21A | 5USF172F10H6 | PANEL 2 (CNM) | ₹ 42 | 1 | FOR CNM | |
| 21B | 5USF172F20P0 | PANEL 2 (LYNM9) | ₹ 38 | 1 | FOR LYNM9 | |
| 21C | 5USF172F00H9 | PANEL 2 (BG) | ₹ 30 | 1 | FOR BG | |
| 22 | 901590617800 | SCREW W/WASHER | ₹ 3 | 1 | ||
| 23 | 5USF840F0000 | BACK REST ASSY | ₹ 180 | 1 | ||
| 24 | 5USF164F0000 | STAY-1 | ₹ 95 | 1 | ||
| 25 | 901110881600 | BOLT HEX HD BUTTON | ₹ 24 | 2 | ||
| 26 | 901760880400 | NUT CAP | ₹ 3 | 2 | ||
| 27 | 958170802000 | BOLT FLANGE | ₹ 8 | 2 | ||
| 28 | 5USF164G0000 | STAY-2 | ₹ 95 | 1 | ||
| 29 | 901110881600 | BOLT HEX HD BUTTON | ₹ 24 | 2 | ||
| 30 | 901760880400 | NUT CAP | ₹ 3 | 2 | ||
| 31 | 958170802000 | BOLT FLANGE | ₹ 8 | 2 | ||
| 32 | 5USF164H0000 | 5USF164H0000 | ₹ 0 | 1 | ||
| 33 | 957070650000 | NUT FLANGE | ₹ 5 | 2 | ||
| 34 | 5USF842M0000 | COVER 1 | ₹ 13 | 1 | ||
| 35 | 9760N0621600 | PAN HEAD SCREW | ₹ 3 | 1 | ||
| 36 | 5USF157B0000 | EMBLEM 1 | ₹ 48 | 1 | ||
| 37 | 5USF16290000 | 5USF16290000 | ₹ 0 | 1 | ||
| 38 | 901190610800 | BOLT WITH WASHER | ₹ 6 | 1 | ||
| 39 | 901830581800 | NUT SPRING | ₹ 9 | 2 | ||
| 40 | 958270602500 | BOLT FLANGE | ₹ 6 | 4 | ||
| 41 | 5USF15811000 | STAY PLATE FITTING 1 | ₹ 10 | 1 | ||
| 42 | 5USF34850000 | 5USF34850000 | ₹ 0 | 1 | ||
| 43 | 5USF16811000 | 5USF16811000 | ₹ 0 | 1 | ||
| 44 | 5USH51100100 | REFLECTOR ASSY | ₹ 16 | 1 | ||
| 45 | 957070550000 | NUT FLANGE | ₹ 1 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 5US1 ENTICER Series FENDER
