FENDER
0
5YYH
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 5YYF151010P0 | FRONT FENDER COMP.( DRMK ) RED | ₹ 1200 | 1 | FOR DRMK | |
| 1B | 5YYF151010PA | FRONTFENDERCOMP-DRYC1(YELLOW | ₹ 1200 | 1 | FOR DRYC1 | |
| 2 | 958270601600 | BOLT FLANGE | ₹ 5 | 4 | ||
| 3 | 5TSF15180100 | HOLDER, CABLE | ₹ 25 | 1 | ||
| 4 | 5YYF16110100 | FENDER, REAR | ₹ 234 | 1 | ||
| 5 | 901190610800 | BOLT WITH WASHER | ₹ 6 | 3 | ||
| 6 | 5TSF16850000 | BRACKET LICENCE | ₹ 66 | 1 | ||
| 7 | 901190610800 | BOLT WITH WASHER | ₹ 6 | 2 | ||
| 8 | 904641082900 | CLAMP | ₹ 6 | 1 | ||
| 9 | 5USH51100100 | REFLECTOR ASSY | ₹ 16 | 1 | ||
| 10 | 957070550000 | NUT FLANGE | ₹ 1 | 1 | ||
| 11 | 5YYF16910000 | FLAP REAR FENDER | ₹ 11 | 1 | ||
| 12 | 9850N0501200 | SCREW PAN HEAD | ₹ 2 | 2 | ||
| 13 | 902010572500 | WASHER PLAIN | ₹ 40 | 2 | ||
| 14 | 9530N0560000 | NUT HEX | ₹ 2 | 2 | ||
| 15 | 21CF16810000 | PLATE LICENSE | ₹ 45 | 1 | ||
| 16 | 9850N0601200 | SCREW PAN HEAD | ₹ 2 | 2 | ||
| 17 | 9290N0610000 | WASHER, SPRING | ₹ 1 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA 5YYH GLADIATOR Series FENDER
