FENDER
B1N2
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | B1NF151100P4 | FENDER FRONT | ₹ 608 | 1 | FOR VRC1 | |
| 1B | B1NF151100P1 | FENDER FRONT | ₹ 608 | 1 | FOR SMX | |
| 2 | 90387068C500 | COLLAR | ₹ 8 | 4 | ||
| 3 | 904800880100 | GROMMET | ₹ 10 | 4 | ||
| 4 | 958070602000 | BOLT FLANGE | ₹ 5 | 2 | ||
| 5 | 901110686800 | BOLT HEX. SOCKET BUTTON | ₹ 26 | 2 | ||
| 6 | 2GSF16111000 | FENDER REAR | ₹ 207 | 1 | ||
| 7 | 970120601400 | BOLT | ₹ 5 | 2 | ||
| 8 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 9 | 90105068C600 | BOLT, FLANGE | ₹ 0 | 4 | ||
| 10 | 903870807900 | COLLAR | ₹ 81 | 4 | ||
| 11 | 4UUF811G0000 | BAND ASSY | ₹ 11 | 1 | ||
| 12 | 2GSF16131000 | STAY FENDER 1 | ₹ 156 | 1 | ||
| 13 | 2GSF16141000 | STAY FENDER 2 | ₹ 156 | 1 | ||
| 14 | 2GSF16511000 | COVER REAR FENDER | ₹ 193 | 1 | ||
| 15 | 2GSF163A0000 | COVER 1 | ₹ 55 | 1 | ||
| 16 | 901490682900 | SCREW | ₹ 25 | 2 | ||
| 17 | 901830606900 | NUT SPRING | ₹ 159 | 2 | ||
| 18 | 970120601400 | BOLT | ₹ 5 | 2 | ||
| 19 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 20 | 2GSF81001000 | TOOL SET | ₹ 85 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Protecting the Yamaha FZS V2 from road debris is the task of the Fender assembly. This kit includes the Fender Front plus the Fender Rear for complete coverage. The front unit prevents water plus mud from splashing onto the engine plus rider. It is secured by the Bolt Flange plus specialized Collars for a rigid mount. The Fender Rear houses the license plate plus provides rear end protection. Every Grommet plus Damper absorbs vibrations to prevent cracking of the plastic. Authentic parts like the Stay Fender 1 plus Stay Fender 2 ensure a stable fitment for the rear assembly. This system is vital for maintaining the cleanliness plus longevity of the motorcycle. The Cover Rear Fender plus Cover 1 complete the sleek look of the rear bodywork. High quality materials resist fading from UV exposure plus impact from stones. It ensures the motorcycle remains looking sharp while providing essential protection. This collection of parts is a must for any maintenance or restoration project.
