HEADLIGHT
B2N2
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2GSH43001000 | HEADLIGHT ASSY | ₹ 1275 | 1 | ||
| 2 | 2GSH430A1000 | HEADLIGHT UNIT ASS | ₹ 810 | 1 | ||
| 3 | 5TSH43140000 | BULB(12V-35W/35W-HALOGEN) | ₹ 150 | 1 | ||
| 4 | 2LPH43470000 | BULB ( 12V-5W ) | ₹ 23 | 1 | ||
| 5 | B62H43350000 | SPRING | ₹ 7 | 1 | ||
| 6 | 2LPH45260000 | SCREW | ₹ 3 | 1 | ||
| 7 | 2GSH45020000 | COVER COMP. | ₹ 60 | 1 | ||
| 8 | 977074051200 | SCREW TAPPING | ₹ 4 | 2 | ||
| 9 | 2GSH43181000 | STAY HEADLIGHT 1 | ₹ 28 | 1 | ||
| 10 | 2GSH43120000 | CORD ASSY | ₹ 42 | 1 | ||
| 11 | 904801410100 | GROMMET | ₹ 10 | 2 | ||
| 12 | 90387068D400 | COLLAR | ₹ 7 | 2 | ||
| 13 | 958020602500 | BOLT FLANGE | ₹ 6 | 2 | ||
| 14 | 958120601200 | BOLT FLANGE | ₹ 3 | 1 | ||
| 15 | 901830606900 | NUT SPRING | ₹ 159 | 3 | ||
| 16 | 2GSF31210000 | COVER UPPER 1 | ₹ 64 | 1 | ||
| 17 | 902690681400 | RIVET | ₹ 8 | 3 | ||
| 18A | 2GSF312200P3 | COVER OUTER 1-SMX(BLACK METAL | ₹ 230 | 1 | FOR MNM3,BWC1 | |
| 18B | 2GSF312200P6 | COVER OUTER 1 -S3(SILVER) | ₹ 230 | 1 | FOR MDRM4 | |
| 18C | 2GSF312200P7 | COVER OUTER 1 -CM6(CYAN METAL | ₹ 230 | 1 | FOR CM6 | |
| 19A | 2GSF313200P3 | COVER OUTER 2-SMX(BLACK METAL | ₹ 230 | 1 | FOR MNM3,BWC1 | |
| 19B | 2GSF313200P6 | COVER OUTER 2 -S3(SILVER) | ₹ 230 | 1 | FOR MDRM4 | |
| 19C | 2GSF313200P7 | COVER OUTER 2 -CM6(CYAN METAL | ₹ 230 | 1 | FOR CM6 | |
| 20 | 901600581200 | SCREW ROUND TAPPING | ₹ 10 | 2 | ||
| 21A | 2GSF312300P3 | COVER UNDER 1-CM6(CYAN METALL | ₹ 285 | 1 | FOR MNM3 | |
| 21B | 2GSF312300P2 | COVER UNDER 1-BWC1(WHITE) | ₹ 285 | 1 | FOR BWC1 | |
| 21C | 2GSF312300P4 | COVER LOWER 1 -MDRM4(DULL RED | ₹ 285 | 1 | FOR MDRM4 | |
| 21D | 2GSF312300P5 | COVER LOWER 1 | ₹ 285 | 1 | FOR CM6 | |
| 22 | 902690681400 | RIVET | ₹ 8 | 4 | ||
| 23 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 24 | 901830580700 | NUT SPRING | ₹ 9 | 3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Piercing through the darkness requires the advanced Headlight assembly of the Yamaha FZS V2 providing the clarity needed for safe travel. The high output Bulb halogen creates a wide plus consistent beam pattern that illuminates the unpredictable Indian road surfaces with ease. Supporting this optical system is the robust Stay headlight one which ensures the unit remains perfectly aligned even on bumpy rural terrains. The distinctive streetfighter aesthetic is enhanced by the Cover comp which adds a muscular presence to the front of the motorcycle. Every Grommet plus Collar within this assembly is engineered to dampen engine vibrations plus protect the sensitive electrical connections from damage. The Cord assy routes power efficiently to the main lamp plus the secondary pilot light for constant visibility. Investing in authentic headlight components preserves the look while prioritizing safety.
