HEADLIGHT
B2N3/B2N4
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2GSH43001000 | HEADLIGHT ASSY | ₹ 1275 | 1 | ||
| 2 | 2GSH430A1000 | HEADLIGHT UNIT ASS | ₹ 810 | 1 | ||
| 3 | 5TSH43140000 | BULB(12V-35W/35W-HALOGEN) | ₹ 150 | 1 | ||
| 4 | 2LPH43470000 | BULB ( 12V-5W ) | ₹ 23 | 1 | ||
| 5 | B62H43350000 | SPRING | ₹ 7 | 1 | ||
| 6 | 2LPH45260000 | SCREW | ₹ 3 | 1 | ||
| 7 | 2GSH45020000 | COVER COMP. | ₹ 60 | 1 | ||
| 8 | 977074051200 | SCREW TAPPING | ₹ 4 | 2 | ||
| 9 | 2GSH43181000 | STAY HEADLIGHT 1 | ₹ 28 | 1 | ||
| 10 | 2GSH43120000 | CORD ASSY | ₹ 42 | 1 | ||
| 11 | 904801410100 | GROMMET | ₹ 10 | 2 | ||
| 12 | 90387068D400 | COLLAR | ₹ 7 | 2 | ||
| 13 | 958020602500 | BOLT FLANGE | ₹ 6 | 2 | ||
| 14 | 958120601200 | BOLT FLANGE | ₹ 3 | 1 | ||
| 15 | 901830606900 | NUT SPRING | ₹ 159 | 3 | ||
| 16 | 2GSF31210000 | COVER UPPER 1 | ₹ 64 | 1 | ||
| 17 | 902690681400 | RIVET | ₹ 8 | 3 | ||
| 18 | 2GSXF31250P3 | COVER OUTER 1 -SMX(BLACK META | ₹ 244 | 1 | FOR MBL2 | |
| 19 | 2GSXF31350P3 | COVER OUTER 2 -SMX(BLACK META | ₹ 244 | 1 | FOR MBL2 | |
| 20 | 901600581200 | SCREW ROUND TAPPING | ₹ 10 | 2 | ||
| 21 | 2GSF312300P0 | COVER UNDER 1 - MBL2 (MAT BLA | ₹ 290 | 1 | FOR MBL2 | |
| 22 | 902690681400 | RIVET | ₹ 8 | 4 | ||
| 23 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 24 | 901830580700 | NUT SPRING | ₹ 9 | 3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The aggressive face of the Yamaha FZS V2 is illuminated by the premium Headlight assembly. This system features a powerful Headlight unit assy designed for maximum road clarity during nighttime rides. The unit is supported by a robust Stay headlight together with various nut spring hardware for a secure mount on the front. Protective elements like the Cover comp together with the upper cover provide an aerodynamic finish while shielding the electronics. The illumination is provided by a high output Halogen bulb which cuts through dust and smog. Every Collar and Bolt flange ensures the light remains aligned even on the bumpiest rural roads. Using genuine headlight parts ensures that the lens stays clear and the beam pattern remains consistent. This module provides the confidence needed for navigating through unpredictable road conditions after sunset. It combines cutting edge design with essential safety functionality. Style and vision are perfectly integrated in this front end.
