B2UK
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B2UXF15110P1 | FENDER FRONT | ₹ 691 | 1 | FOR SMX | |
| 2 | B7JF15410000 | DAMPER 1 | ₹ 10 | 1 | ||
| 3 | B7JF15693000 | GRAPHIC 1 | ₹ 10 | 2 | ||
| 4 | 90387068T800 | COLLAR | ₹ 16 | 3 | ||
| 5 | 958120601600 | BOLT FLANGE | ₹ 3 | 3 | ||
| 6 | B2UF16110000 | FENDER REAR | ₹ 317 | 1 | ||
| 7 | 90387068S100 | COLLAR | ₹ 12 | 4 | ||
| 8 | 958120601400 | BOLT FLANGE | ₹ 5 | 4 | ||
| 9 | B7JF16210100 | FLAP | ₹ 25 | 1 | ||
| 10 | B7JF16910100 | FLAP | ₹ 32 | 1 | ||
| 11 | 901830506700 | NUT SPRING | ₹ 8 | 1 | ||
| 12 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 13 | 2FCH51110000 | REFLECTOR FRONT 1 | ₹ 23 | 2 | ||
| 14 | 957070550000 | NUT FLANGE | ₹ 1 | 2 | ||
| 15 | B2UF16510000 | COVER REAR FENDER | ₹ 42 | 1 | ||
| 16 | 977025001600 | SCREW TAPPING | ₹ 10 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Protect your Yamaha RayZR and keep its clean lines sharp with the Fender assembly, designed for both function and form. This category features the robust fender front, enhanced by graphic 1 for a custom look, and the essential fender rear for maximum splash protection. To ensure a quiet and stable ride, we include the damper 1, collar, and bolt flange for a vibration-free mount. Additional coverage is provided by the flap and cover rear fender, which shield the engine and rider from road spray. Safety is enhanced with the reflector front 1, while every nut spring, nut flange, and screw tapping is provided for a precise, factory-standard installation. This level of technical clarity gives buyers the purchase confidence that their fenders will remain secure and effective over thousands of miles. By choosing genuine Yamaha fender parts, you ensure your RayZR stays protected from the elements while maintaining its signature aggressive look. Keep your ride clean and your style intact with components engineered specifically for your scooters unique urban architecture.
