HEAD LIGHT
B3N1/B3N2
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2GSH43001000 | HEADLIGHT ASSY | ₹ 1275 | 1 | ||
| 2 | 2GSH430A1000 | HEADLIGHT UNIT ASS | ₹ 810 | 1 | ||
| 3 | 5TSH43140000 | BULB(12V-35W/35W-HALOGEN) | ₹ 150 | 1 | ||
| 4 | 2LPH43470000 | BULB ( 12V-5W ) | ₹ 23 | 1 | ||
| 5 | B62H43350000 | SPRING | ₹ 7 | 1 | ||
| 6 | 2LPH45260000 | SCREW | ₹ 3 | 1 | ||
| 7 | 2GSH45020000 | COVER COMP. | ₹ 60 | 1 | ||
| 8 | 977074051200 | SCREW TAPPING | ₹ 4 | 2 | ||
| 9 | 2GSH43181000 | STAY HEADLIGHT 1 | ₹ 28 | 1 | ||
| 10 | 2GSH43120000 | CORD ASSY | ₹ 42 | 1 | ||
| 11 | 904801410100 | GROMMET | ₹ 10 | 2 | ||
| 12 | 90387068D400 | COLLAR | ₹ 7 | 2 | ||
| 13 | 958020602500 | BOLT FLANGE | ₹ 6 | 2 | ||
| 14 | 958120601200 | BOLT FLANGE | ₹ 3 | 1 | ||
| 15 | 901830606900 | NUT SPRING | ₹ 159 | 3 | ||
| 16 | 2GSF31210000 | COVER UPPER 1 | ₹ 64 | 1 | ||
| 17 | 902690681400 | RIVET | ₹ 8 | 3 | ||
| 18 | 2GSF312200P2 | COVER OUTER 1 -MBL2(MAT BLACK | ₹ 230 | 1 | FOR MDPBM1 | |
| 19 | 2GSF313200P2 | COVER OUTER 2-MBL2(MAT BLACK) | ₹ 230 | 1 | FOR MDPBM1 | |
| 20 | 901600581200 | SCREW ROUND TAPPING | ₹ 10 | 2 | ||
| 21 | 2GSF312300P6 | COVER LOWER 1 -MDPBM1(DARK P | ₹ 285 | 1 | FOR MDPBM1 | |
| 22 | 902690681400 | RIVET | ₹ 8 | 4 | ||
| 23 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 24 | 901830580700 | NUT SPRING | ₹ 9 | 3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Piercing through the darkness requires the advanced Head Light assembly of the Yamaha FZS V2 which features modern lighting technology. This system utilizes a dedicated Headlight unit ass together with the high output Bulb halogen to provide maximum road illumination. The housing is secured using specialized Nut spring and Screw tapping hardware for a flush aerodynamic fit on the front. Protective elements like the Cover comp and various Grommets ensure that the internal electronics remain isolated from engine vibrations. The distinctive look of the motorcycle is enhanced by the Cover outer panels which give the front end its aggressive streetfighter personality. Every Collar and Screw within this setup is engineered to maintain precise alignment of the light beam. Using genuine headlight components ensures a safer night riding experience across India. This assembly provides the clarity needed to spot potholes or obstacles well in advance. Style meets function in this module.
