HEAD LIGHT
B3N3
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 2GSH43001000 | HEADLIGHT ASSY | ₹ 1275 | 1 | ||
| 2 | 2GSH430A1000 | HEADLIGHT UNIT ASS | ₹ 810 | 1 | ||
| 3 | 5TSH43140000 | BULB(12V-35W/35W-HALOGEN) | ₹ 150 | 1 | ||
| 4 | 2LPH43470000 | BULB ( 12V-5W ) | ₹ 23 | 1 | ||
| 5 | B62H43350000 | SPRING | ₹ 7 | 1 | ||
| 6 | 2LPH45260000 | SCREW | ₹ 3 | 1 | ||
| 7 | 2GSH45020000 | COVER COMP. | ₹ 60 | 1 | ||
| 8 | 977074051200 | SCREW TAPPING | ₹ 4 | 2 | ||
| 9 | 2GSH43181000 | STAY HEADLIGHT 1 | ₹ 28 | 1 | ||
| 10 | 2GSH43120000 | CORD ASSY | ₹ 42 | 1 | ||
| 11 | 904801410100 | GROMMET | ₹ 10 | 2 | ||
| 12 | 90387068D400 | COLLAR | ₹ 7 | 2 | ||
| 13 | 958020602500 | BOLT FLANGE | ₹ 6 | 2 | ||
| 14 | 958120601200 | BOLT FLANGE | ₹ 3 | 1 | ||
| 15 | 901830606900 | NUT SPRING | ₹ 159 | 3 | ||
| 16 | 2GSF31210000 | COVER UPPER 1 | ₹ 64 | 1 | ||
| 17 | 902690681400 | RIVET | ₹ 8 | 3 | ||
| 18 | 2GSXF31240P2 | COVER OUTER 1 -MAT BLACK2 | ₹ 228 | 1 | FOR MBL2 | |
| 19 | 2GSXF31340P2 | COVER OUTER 2 -MAT BLACK2 | ₹ 228 | 1 | FOR MBL2 | |
| 20 | 901600581200 | SCREW ROUND TAPPING | ₹ 10 | 2 | ||
| 21 | 2GSF312300V9 | COVER LOWER 1 -NHG(SPARKLE GR | ₹ 239 | 1 | FOR MBL2 | |
| 22 | 902690681400 | RIVET | ₹ 8 | 4 | ||
| 23 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 24 | 901830580700 | NUT SPRING | ₹ 9 | 3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Piercing through the darkness requires the advanced Head Light assembly of the Yamaha FZS V2 providing the clarity needed for safe night travel. The high output Bulb halogen creates a wide and consistent beam pattern that illuminates the unpredictable Indian road surfaces with ease. Supporting this optical system is the robust Stay headlight which ensures the unit remains perfectly aligned even on the bumpiest rural terrains. The distinctive streetfighter aesthetic is enhanced by the Cover comp which adds a muscular presence to the front of the motorcycle. Every Grommet and Collar within this assembly is engineered to dampen engine vibrations and protect the sensitive electrical connections. The Cord assy routes power efficiently to the main lamp and the secondary pilot light for constant visibility. Investing in authentic headlight components preserves the look of your machine while prioritizing the safety of the rider during every sunset journey.
