Yamaha RAYZ B822 Fender | IndiaSpare

B822

YAMAHA B822 RAYZ Series FENDER
Fullscreen
Ref No Part No Part Name Rate Qnty Order Remarks
1A 1GCXF15130P8 FENDER FRONT -CM6(CYAN METALL ₹ 709 1 FOR MBL2
1B 1GCXF15130P9 FENDER FRONT-MBL2(MAT BLACK) ₹ 709 1 FOR BWC1
1C 1GCXF15130P4 FENDER FRONT -VRC1(VIVID RED) ₹ 709 1 FOR VRC1
1D 1GCXF15130P5 FENDER FRONT -DPBMY(PURPLE B ₹ 709 1 FOR DPBMY
2 90387068S100 COLLAR ₹ 12 3
3 958120601400 BOLT FLANGE ₹ 5 3
4 1GCF16110000 FENDER REAR ₹ 128 1
5 901090620200 BOLT ₹ 13 3
6 90387068M600 COLLAR ₹ 11 1
7 901190620900 BOLT WITH WASHER ₹ 17 1
8 1GCF16120000 BRACKET REAR FENDER ₹ 20 1
9 958120601400 BOLT FLANGE ₹ 5 1
10 2FSF16290000 GUARD MUD ₹ 279 1
11 901090620200 BOLT ₹ 13 2
12 901190613700 BOLT WITH WASHER ₹ 9 2
13 901830580700 NUT SPRING ₹ 9 2
14 2FSF16210000 FLAP ₹ 18 1
15 5USH51100100 REFLECTOR ASSY ₹ 14 1
16 957020550000 NUT FLANGE ₹ 2 1


Color Legend:

  • Red: Canceled part - unavailable for any operations.
  • Blue: Part of a kit - cannot be ordered individually.
  • Gray (Dimmed): Disabled part - non-interactive for various reasons.
  • Part Number : Superseded part - replaced by a newer part.

Description: - Guard your scooter against the elements with our durable Fender components, designed for both protection and style. The Fender Front is available in Cyan Metallic, Mat Black, Vivid Red, and Purple Blue finishes, secured by the Collar and Bolt Flange. For the rear, the Fender Rear and Bracket Rear Fender provide a robust shield against mud and water spray, supported by the Guard Mud and Flap. Every mounting point is reinforced with the Bolt with Washer and Collar for a secure, vibration-free fit. Safety is enhanced with the Reflector Assy and Nut Flange, ensuring you remain visible from all angles. We also include the specialized Bolt Hex. Socket Button and Nut Spring hardware to keep your fenders firmly attached over years of use. These parts offer the technical clarity and purchase confidence required for a clean and safe ride. By choosing genuine fenders, you protect your engine and electrical components from road spray, ensuring that your vehicle stays cleaner and its parts last longer, regardless of the weather conditions you encounter.
