FENDER
B971
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 21CF151100P7 | FENDER FRONT -SMX(BLACK META | ₹ 848 | 1 | FOR CM6 | |
| 1B | 21CF151100P9 | FENDER FRONT -BWC1(WHITE) | ₹ 848 | 1 | FOR BWC1 | |
| 1C | 21CF151100PA | FENDER FRONT -MBL2(MAT BLACK) | ₹ 848 | 1 | FOR SMX | |
| 2 | 90387068C500 | COLLAR | ₹ 8 | 4 | ||
| 3 | 904800880100 | GROMMET | ₹ 10 | 4 | ||
| 4 | 958070602000 | BOLT FLANGE | ₹ 5 | 2 | ||
| 5 | 901110686800 | BOLT HEX. SOCKET BUTTON | ₹ 26 | 2 | ||
| 6 | B97F16110100 | FENDER REAR | ₹ 207 | 1 | ||
| 7 | 905200780600 | DAMPER PLATE | ₹ 8 | 1 | ||
| 8 | 20PF83710000 | DAMPER | ₹ 3 | 3 | ||
| 9 | 970120601400 | BOLT | ₹ 5 | 2 | ||
| 10 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 11 | 956020620000 | NUT, SELF-LOCKING | ₹ 0 | 4 | ||
| 12 | 90387068H800 | COLLAR | ₹ 5 | 4 | ||
| 13 | B97F16400000 | REAR STAY COMP. | ₹ 190 | 1 | ||
| 14 | 901110685900 | BOLT HEX. SOCKET BUTTON | ₹ 7 | 1 | ||
| 15 | B97F16290000 | GUARD MUD | ₹ 78 | 1 | ||
| 16 | 21CF17170000 | DAMPER | ₹ 2 | 1 | ||
| 17 | 977025001600 | SCREW TAPPING | ₹ 10 | 4 | ||
| 18 | B97F163A0000 | COVER REAR FENDER 1 | ₹ 55 | 1 | ||
| 19 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 20 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 2 | ||
| 21 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 22 | B97F81000000 | TOOL SET | ₹ 74 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Staying clean plus looking sharp on Indian roads is easy with the high quality Fender assembly of the Yamaha FZ 25 motorcycle. This section features the Fender Front in various finishes plus the Fender Rear which are designed to effectively channel mud plus water away from the rider. High quality Damper plus Collar components ensure that the fenders remain stable plus vibration free even when riding on the roughest of road surfaces. The inclusion of the Guard Mud plus Rear Stay Comp provides additional coverage plus structural support for the rear wheel area during the monsoon. Every Bolt Flange plus Bolt Hex Socket Button allows for a secure plus clean fitment that perfectly matches the aggressive styling of the bike. The Tool Set included in this assembly ensures you have the basic equipment needed for minor roadside maintenance during your motorcycling adventures. Choosing genuine fender parts guarantees that your motorcycle stays protected.
