FENDER
B972
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 21CXF151G0P3 | FR.FENDER ASSY CM6 | ₹ 848 | 1 | FOR SMX | |
| 1B | 21CXF151G0P7 | FR.FENDER ASSY SMX | ₹ 848 | 1 | FOR MBL2 | |
| 1C | 21CXF151G0P8 | FR.FENDER ASSY MNM3 | ₹ 848 | 1 | FOR MDPBM1 | |
| 2 | B9EF843G0000 | GRAPHIC 3 | ₹ 12 | 2 | ||
| 3 | 90387068C500 | COLLAR | ₹ 8 | 4 | ||
| 4 | 904800880100 | GROMMET | ₹ 10 | 4 | ||
| 5 | 958070602000 | BOLT FLANGE | ₹ 5 | 2 | ||
| 6 | 901110686800 | BOLT HEX. SOCKET BUTTON | ₹ 26 | 2 | ||
| 7 | B97F16110100 | FENDER REAR | ₹ 207 | 1 | ||
| 8 | 905200780600 | DAMPER PLATE | ₹ 8 | 1 | ||
| 9 | 20PF83710000 | DAMPER | ₹ 3 | 3 | ||
| 10 | 970120601400 | BOLT | ₹ 5 | 2 | ||
| 11 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 12 | 956020620000 | NUT, SELF-LOCKING | ₹ 0 | 4 | ||
| 13 | 90387068H800 | COLLAR | ₹ 5 | 4 | ||
| 14 | B97F16400000 | REAR STAY COMP. | ₹ 190 | 1 | ||
| 15 | 901110685900 | BOLT HEX. SOCKET BUTTON | ₹ 7 | 1 | ||
| 16 | B97F16290000 | GUARD MUD | ₹ 78 | 1 | ||
| 17 | 21CF17170000 | DAMPER | ₹ 2 | 1 | ||
| 18 | 977025001600 | SCREW TAPPING | ₹ 10 | 4 | ||
| 19 | B97F163A0000 | COVER REAR FENDER 1 | ₹ 55 | 1 | ||
| 20 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 21 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 2 | ||
| 22 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 23 | B97F81000000 | TOOL SET | ₹ 74 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Protection from road debris plus a sporty look are provided by the Fender assembly of the Yamaha FZ 25 for Indian riders. This section features the Front Fender Assy plus the Fender Rear which are designed to channel water plus mud away from the rider plus the engine. High quality Damper plus Collar components ensure that the fenders remain stable plus vibration free even on the roughest road surfaces. The inclusion of the Guard Mud plus Rear Stay Comp provides additional structural support plus coverage for the rear wheel area. Every Bolt Flange plus Bolt Hex Socket Button allows for a secure fitment that complements the aggressive styling of the motorcycle. The Tool Set included in this assembly ensures that you have the basic equipment needed for minor roadside adjustments during your travels. Choosing genuine fender parts guarantees that your motorcycle stays clean plus looks its best throughout every season.
