HEADLIGHT
B9X5
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B9XH43000000 | HEADLIGHT ASSY | ₹ 13546 | 1 | ||
| 2 | B9TH43100000 | .HEADLIGHT UNIT ASSY | ₹ 0 | 1 | ||
| 3 | 901490603000 | SCREW | ₹ 62 | 2 | ||
| 4 | B9XH54900000 | LIGHT CONTROL UNIT | ₹ 0 | 1 | ||
| 5 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 6 | B9XH41480000 | .WIRE, LEAD 1 | ₹ 0 | 1 | ||
| 7 | 904800181100 | GROMMET | ₹ 8 | 2 | ||
| 8 | 20PF17490000 | COLLAR | ₹ 4 | 2 | ||
| 9 | 904801281500 | GROMMET | ₹ 8 | 2 | ||
| 10 | 90387068C500 | COLLAR | ₹ 8 | 2 | ||
| 11 | 901490682900 | SCREW | ₹ 25 | 4 | ||
| 12 | 977025001600 | SCREW TAPPING | ₹ 10 | 4 | ||
| 13 | 977025001600 | SCREW TAPPING | ₹ 10 | 2 | ||
| 14 | B9XH43010000 | PILOT LIGHT ASSY 1 | ₹ 1874 | 1 | ||
| 15 | 901830581800 | NUT SPRING | ₹ 9 | 4 | ||
| 16 | 977025001600 | SCREW TAPPING | ₹ 10 | 3 | ||
| 17 | B9XF63260000 | GROMMET | ₹ 10 | 3 | ||
| 18 | B9XH355900P1 | COVER METER | ₹ 236 | 1 | FOR SMX | |
| 19 | B9XF34870000 | STAY PLATE | ₹ 94 | 1 | ||
| 20 | 920170502000 | BOLT BUTTON HEAD | ₹ 38 | 4 | ||
| 21 | B9XF31210000 | COVER UPPER 1 | ₹ 103 | 1 | ||
| 22 | 901790580400 | NUT | ₹ 10 | 4 | ||
| 23 | 901830581800 | NUT SPRING | ₹ 9 | 1 | ||
| 24 | B9XXF31210P1 | COVER OUTER 1 | ₹ 333 | 1 | FOR SMX | |
| 25 | B9EF839G0000 | GRAPHIC 10 | ₹ 36 | 1 | ||
| 26 | B97F83910000 | GRAPHIC 1 | ₹ 28 | 1 | ||
| 27 | 901830581800 | NUT SPRING | ₹ 9 | 2 | ||
| 28 | B9XXF31310P1 | COVER OUTER 2 | ₹ 333 | 1 | FOR SMX | |
| 29 | B9EF839G0000 | GRAPHIC 10 | ₹ 36 | 1 | ||
| 30 | B97F83920000 | GRAPHIC 2 | ₹ 28 | 1 | ||
| 31 | 901830581800 | NUT SPRING | ₹ 9 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Navigating through the darkness of highway stretches plus lit city lanes requires a front lighting system that provides absolute clarity. This advanced headlight assembly delivers a powerful beam that illuminates the road ahead with exceptional focus plus brightness. Utilizing the headlight unit assy along with a light control unit, the system manages energy efficiently while providing a superior lighting profile. The sleek outer covers not only protect the optics but also enhance the aggressive street fighter look of the motorcycle. Every grommet, collar, nut spring is manufactured to withstand the constant wind pressure plus road vibrations common on Indian routes. By choosing this original assembly, you ensure your vision remains uncompromised, allowing for faster reactions plus a more confident riding experience. Experience the peace of mind that comes from precision Japanese engineering, where every detail is designed to help you see, be seen, on every journey.
