HEADLIGHT
BAC3/B9P3/BACC/B9PC
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B4GH43000000 | HEADLIGHT ASSY | ₹ 3222 | 1 | ||
| 2 | 2LPH43470000 | BULB ( 12V-5W ) | ₹ 23 | 1 | ||
| 3 | B4GH43120000 | HOLDER SOCKET | ₹ 145 | 1 | ||
| 4 | 904801410100 | GROMMET | ₹ 10 | 2 | ||
| 5 | 90387068D400 | COLLAR | ₹ 7 | 2 | ||
| 6 | 958270602500 | BOLT FLANGE | ₹ 6 | 2 | ||
| 7 | 901830606900 | NUT SPRING | ₹ 159 | 2 | ||
| 8 | B4GF31750000 | BRACKET HEADLIGHT STAY 1 | ₹ 79 | 1 | ||
| 9 | 901830606900 | NUT SPRING | ₹ 159 | 2 | ||
| 10 | 958270801600 | BOLT FLANGE | ₹ 10 | 2 | ||
| 11 | B4GF31210000 | COVER UPPER 1 | ₹ 82 | 1 | ||
| 12 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 | ||
| 13 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 14 | 958270801600 | BOLT FLANGE | ₹ 10 | 1 | ||
| 15 | 90387068N200 | COLLAR | ₹ 11 | 1 | ||
| 16 | B4GF312200P2 | COVER OUTER 1 MBL2 | ₹ 132 | 1 | FOR MBL2 | |
| 17 | 901600581200 | SCREW ROUND TAPPING | ₹ 10 | 1 | ||
| 18 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 19 | B4GF313200P2 | COVER OUTER 2 MBL2 | ₹ 132 | 1 | FOR MBL2 | |
| 20 | 901600581200 | SCREW ROUND TAPPING | ₹ 10 | 1 | ||
| 21 | 901830580700 | NUT SPRING | ₹ 9 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - illuminating the path forward, the lighting system of the Yamaha FZS V3 is engineered for maximum visibility. the headlight assy serves as the primary beacon, casting a powerful beam across the diverse Indian landscape. inside, the high performance bulb generates a steady light that reveals road hazards well in advance. to protect the reflectors, the cover upper plus outer panels provide a sturdy shield against debris plus weather. aerodynamic styling ensures the light unit contributes to the overall stability of the street fighter. every collar, grommet, plus bolt flange is engineered for a secure fitment that resists engine vibration. maintaining the alignment of the headlight is essential for safe riding after sunset. experience the clarity plus confidence provided by a well functioning lighting system, making every journey through dark roads safer. this forward beacon remains a key part of the motorcycle identity, combining practical utility with the fierce look that defines the machine. visibility beacon.
