FENDER
BAC6/B9P6
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B4GF15110000 | FENDER FRONT | ₹ 234 | 1 | ||
| 2 | B4GXF15500P4 | FENDER OVER 1 ASSY. | ₹ 608 | 1 | FOR MDNCM2 | |
| 3 | B9EF843G0000 | GRAPHIC 3 | ₹ 12 | 1 | ||
| 4 | B4GXF15B00P4 | FENDER OVER 2 ASSY. | ₹ 608 | 1 | FOR MDNCM2 | |
| 5 | B9EF843G0000 | GRAPHIC 3 | ₹ 12 | 1 | ||
| 6 | 90387068C500 | COLLAR | ₹ 8 | 2 | ||
| 7 | 904800880100 | GROMMET | ₹ 10 | 2 | ||
| 8 | 958220602000 | BOLT FLANGE | ₹ 5 | 2 | ||
| 9 | 90387068S500 | COLLAR | ₹ 20 | 2 | ||
| 10 | 904801282400 | GROMMET | ₹ 14 | 2 | ||
| 11 | 901110686800 | BOLT HEX. SOCKET BUTTON | ₹ 26 | 2 | ||
| 12 | B9PF16110000 | FENDER REAR | ₹ 139 | 1 | ||
| 13 | 970120601400 | BOLT | ₹ 5 | 2 | ||
| 14 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 15 | 90105068C600 | BOLT, FLANGE | ₹ 0 | 4 | ||
| 16 | 903870807900 | COLLAR | ₹ 81 | 4 | ||
| 17 | B4GF16130000 | STAY FENDER 1 | ₹ 167 | 1 | ||
| 18 | B4GF16140000 | STAY FENDER 2 | ₹ 167 | 1 | ||
| 19 | B4GF16510000 | COVER REAR FENDER | ₹ 110 | 1 | ||
| 20 | B4GF163A0000 | COVER REAR FENDER 1 | ₹ 24 | 1 | ||
| 21 | 901490682900 | SCREW | ₹ 25 | 2 | ||
| 22 | 901830606900 | NUT SPRING | ₹ 159 | 2 | ||
| 23 | 970120601400 | BOLT | ₹ 5 | 2 | ||
| 24 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 25 | BK7F16410000 | BRACKET REFLECTOR | ₹ 35 | 1 | ||
| 26 | 902674884500 | RIVET BLIND | ₹ 9 | 1 | ||
| 27 | 2FCH51110000 | REFLECTOR FRONT 1 | ₹ 23 | 2 | ||
| 28 | 957070550000 | NUT FLANGE | ₹ 1 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - protection from road spray plus debris is the primary duty of the fender system on the Yamaha FZS V3, ensuring the rider plus the machine stay clean. the fender front is positioned close to the tire to deflect mud plus water away from the engine, while the fender rear shields the tail light plus passenger. this is especially important during the heavy rains of the Indian monsoon season. every collar, grommet, plus bolt is designed to provide a stable mounting that resists vibrations on uneven roads. the assembly also includes specialized stays to reinforce the structure against wind pressure at high speeds. high impact materials ensure the fenders remain durable plus maintain their shape despite constant use. maintaining these parts is essential for keeping the motorcycle clean plus preventing damage to sensitive lighting components. the design complements the aggressive styling of the street fighter, ensuring it looks ready for action in all weather conditions on every single journey.
