FENDER
BACD/B9PD
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B4GF15110000 | FENDER FRONT | ₹ 234 | 1 | ||
| 2A | B4GXF15510P5 | FENDER FRONT 1 | ₹ 608 | 1 | FOR SMX | |
| 2B | B4GXF15510P6 | FENDER FRONT 1 | ₹ 608 | 1 | FOR DPBMY | |
| 3 | B9EF843G0000 | GRAPHIC 3 | ₹ 12 | 1 | ||
| 4A | B4GXF15B10P5 | FENDER FRONT 2 | ₹ 608 | 1 | FOR SMX | |
| 4B | B4GXF15B10P6 | FENDER FRONT 2 | ₹ 608 | 1 | FOR DPBMY | |
| 5 | B9EF843G0000 | GRAPHIC 3 | ₹ 12 | 1 | ||
| 6 | 90387068C500 | COLLAR | ₹ 8 | 2 | ||
| 7 | 904800880100 | GROMMET | ₹ 10 | 2 | ||
| 8 | 958220602000 | BOLT FLANGE | ₹ 5 | 2 | ||
| 9 | 90387068S500 | COLLAR | ₹ 20 | 2 | ||
| 10 | 904801282400 | GROMMET | ₹ 14 | 2 | ||
| 11 | 901110686800 | BOLT HEX. SOCKET BUTTON | ₹ 26 | 2 | ||
| 12 | B9PF16110000 | FENDER REAR | ₹ 139 | 1 | ||
| 13 | 970120601400 | BOLT | ₹ 5 | 2 | ||
| 14 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 15 | 90105068C600 | BOLT, FLANGE | ₹ 0 | 4 | ||
| 16 | 903870807900 | COLLAR | ₹ 81 | 4 | ||
| 17 | B4GF16130000 | STAY FENDER 1 | ₹ 167 | 1 | ||
| 18 | B4GF16140000 | STAY FENDER 2 | ₹ 167 | 1 | ||
| 19 | B4GF16510000 | COVER REAR FENDER | ₹ 110 | 1 | ||
| 20 | B4GF163A0000 | COVER REAR FENDER 1 | ₹ 24 | 1 | ||
| 21 | 901490682900 | SCREW | ₹ 25 | 2 | ||
| 22 | 901830606900 | NUT SPRING | ₹ 159 | 2 | ||
| 23 | 970120601400 | BOLT | ₹ 5 | 2 | ||
| 24 | 903870604800 | COLLAR | ₹ 7 | 2 | ||
| 25 | BK7F16410000 | BRACKET REFLECTOR | ₹ 35 | 1 | ||
| 26 | 902674884500 | RIVET BLIND | ₹ 9 | 1 | ||
| 27 | 2FCH51110000 | REFLECTOR FRONT 1 | ₹ 23 | 2 | ||
| 28 | 957070550000 | NUT FLANGE | ₹ 1 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Staying clean plus looking sharp on Indian roads is easy with the high quality Fender assembly of the Yamaha FZ V3 motorcycle. This section features the Fender Front plus the Fender Rear which are designed to effectively channel mud plus water away from the rider plus the internal mechanics through every season. High quality Damper plus Collar components ensure that the fenders remain stable plus vibration free even when riding on the roughest of road surfaces across the country. The inclusion of the Stay Fender one plus Stay Fender two provides additional coverage plus structural support for the rear wheel area during the heavy monsoon rains. Every Bolt Flange plus specialized Bracket Reflector allows for a secure plus clean fitment that perfectly matches the aggressive styling of the bike. The Cover Rear Fender ensures that the assembly stays protected plus accessible for any adjustments needed during your travels. Choosing genuine fender parts guarantees excellence.
