FENDER
0
BB71
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | 1CKF1511002X | FENDER, FRONT-SMX(BLACK METALL | ₹ 770 | 1 | FOR BWC1 | |
| 1B | 1CKF1511002Y | FENDER, FRONT -LGM6(LEAF GREEN | ₹ 770 | 1 | FOR SMX | |
| 1C | 1CKF1511007X | FENDER, FRONT-1BWC(WHITE) | ₹ 770 | 1 | FOR VRC1 | |
| 2 | 90387068C800 | COLLAR | ₹ 18 | 2 | ||
| 3 | 904801280500 | GROMMET | ₹ 8 | 2 | ||
| 4 | 901110686800 | BOLT HEX. SOCKET BUTTON | ₹ 26 | 2 | ||
| 5 | 904801885900 | GROMMET | ₹ 6 | 2 | ||
| 6 | 901190623300 | BOLT, WITH WASHER | ₹ 21 | 2 | ||
| 7 | BB7F16110000 | FENDER, REAR | ₹ 390 | 1 | ||
| 8 | 901090688700 | BOLT | ₹ 19 | 4 | ||
| 9 | 901090618300 | BOLT | ₹ 16 | 2 | ||
| 10 | 901830581800 | NUT SPRING | ₹ 9 | 6 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA BB71 R15 S Series FENDER
