WINDSHIELD
0
BB71
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | 1CKF83810000 | WINDSHIELD | ₹ 340 | 1 | ||
| 2 | 20PF836R0000 | PANEL, INNER 5 | ₹ 25 | 1 | ||
| 3 | 901500502400 | SCREW ROUND HEAD | ₹ 59 | 4 | ||
| 4 | 901790580400 | NUT | ₹ 10 | 4 | ||
| 5 | 905200281000 | DAMPER PLATE | ₹ 6 | 2 | ||
| 6A | BB7XF83500P1 | PANEL ASSY-SMX(BLACK METALLIC) | ₹ 1100 | 1 | FOR SMX | |
| 6B | BB7XF83510P5 | PANEL ASSY-BWC1(WHITE) | ₹ 1100 | 1 | FOR BWC1 | |
| 6C | BB7XF83520P4 | PANEL ASSY-VRC1(VIVID RED) | ₹ 1100 | 1 | FOR VRC1 | |
| 7 | 90183050A700 | NUT SPRING | ₹ 22 | 8 | ||
| 8 | 904642081500 | CLAMP | ₹ 19 | 1 | ||
| 9 | 904640580200 | CLAMP | ₹ 13 | 1 | ||
| 10 | 2FBF83560000 | STAY 1 | ₹ 550 | 1 | ||
| 11 | 901110883600 | BOLT,HEX. SOCKET BUTTON | ₹ 24 | 2 | ||
| 12 | 904800155800 | GROMMET | ₹ 10 | 2 | ||
| 13 | 2PBF62800100 | REAR VIEW MIRROR ASSY (LEFT) | ₹ 394 | 1 | ||
| 14 | 2PBF62900100 | REAR VIEW MIRROR ASSY (RIGHT) | ₹ 394 | 1 | ||
| 15 | 20PF84830000 | PLATE RUBBER 1 | ₹ 9 | 2 | ||
| 16 | 20PF84840000 | PLATE RUBBER 2 | ₹ 10 | 2 | ||
| 17 | 913170602500 | BOLT | ₹ 11 | 4 | ||
| 18 | 90387068C200 | COLLAR | ₹ 8 | 4 | ||
| 19 | 20PF16850000 | BRACKET LICENSE | ₹ 74 | 1 | ||
| 20 | 20PF34690000 | CAP BOLT | ₹ 2 | 4 | ||
| 21A | 20PF117V11P1 | COVER 7 -SMX(BLACK METALLIC) | ₹ 1130 | 1 | FOR SMX | |
| 21B | 20PF117V11P4 | COVER 7 -VRC1(VIVID RED) | ₹ 1130 | 1 | FOR VRC1 | |
| 21C | 20PF117V11P5 | COVER 7 -BWC1(WHITE) | ₹ 1130 | 1 | FOR BWC1 | |
| 22A | BB7XF11700P1 | COVER 8-SMX(BLACK METALLIC) | ₹ 1782 | 1 | FOR SMX | |
| 22B | BB7XF11700P4 | COVER 8 - VRC1(VIVID RED) | ₹ 1782 | 1 | FOR VRC1 | |
| 22C | BB7XF11700P5 | COVER 8-BWC1(WHITE) | ₹ 1782 | 1 | FOR BWC1 | |
| 23 | 904801400300 | GROMMET | ₹ 8 | 1 | ||
| 24 | 905204000100 | 905204000100 | ₹ 0 | 1 | ||
| 25 | 901110686800 | BOLT HEX. SOCKET BUTTON | ₹ 26 | 2 | ||
| 26 | 904801400300 | GROMMET | ₹ 8 | 1 | ||
| 27 | 90387068C200 | COLLAR | ₹ 8 | 2 | ||
| 28 | 904800155800 | GROMMET | ₹ 10 | 2 | ||
| 29 | 90183050A700 | NUT SPRING | ₹ 22 | 2 | ||
| 30 | 901110500300 | BOLT HEX. SOCKET BUTTON | ₹ 30 | 2 | ||
| 31A | BB7XF83600P4 | PANEL COMP 1 - SMX(BLACK METAL | ₹ 1385 | 1 | FOR SMX | |
| 31B | BB7XF83610P4 | PANEL COMP 1 - SMX(BLACK METAL | ₹ 1385 | 1 | FOR BWC1 | |
| 31C | BB7XF83620P2 | PANEL COMP 1-BWC1(WHITE) | ₹ 1385 | 1 | FOR VRC1 | |
| 32A | BB7XF83G00P4 | PANEL COMP 2 - SMX(BLACK METAL | ₹ 1385 | 1 | FOR SMX | |
| 32B | BB7XF83G10P4 | PANEL COMP 2 - SMX(BLACK METAL | ₹ 1385 | 1 | FOR BWC1 | |
| 32C | BB7XF83G20P2 | PANEL COMP 2-BWC1(WHITE) | ₹ 1385 | 1 | FOR VRC1 | |
| 33 | 977075001200 | SCREW TRUSS HD TAP | ₹ 5 | 6 | ||
| 34 | 901830581800 | NUT SPRING | ₹ 9 | 12 | ||
| 35 | 901110500300 | BOLT HEX. SOCKET BUTTON | ₹ 30 | 8 | ||
| 36 | 20PF837L0000 | PANEL, CONSOLE 1 | ₹ 70 | 1 | ||
| 37 | 20PF837M0000 | PANEL, CONSOLE 2 | ₹ 70 | 1 | ||
| 38 | 901110500200 | BOLT,HEX. SOCKET BUTTON | ₹ 18 | 6 | ||
| 39 | 90387068C400 | COLLAR | ₹ 8 | 2 | ||
| 40 | 902020518000 | WASHER PLATE | ₹ 28 | 10 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA BB71 R15 S Series WINDSHIELD
