LEG SHIELD

Ref No	Part No	Part Name	Rate	Qnty	Order	Remarks
1	BCFF82830000	BRACKET POUCH	₹ 722	1
2	B9DF82841000	BRACKET UNDER	₹ 98	1
3	B9DF137U0200	GUIDE, AIR 1	₹ 131	1
4	901090620200	BOLT	₹ 13	2
5	901100610200	BOLT, HEXAGON SOCKET HEAD	₹ 39	1
6	977075001200	SCREW TRUSS HD TAP	₹ 5	2
7	902690681200	RIVET	₹ 20	1
8	903380718000	PLUG	₹ 84	2
9	904800155900	GROMMET	₹ 10	1
10	904801062300	GROMMET	₹ 8	1
11	901830580700	NUT SPRING	₹ 9	2
12	B9DF83360000	PLATE	₹ 50	1
13	901600581000	SCREW, ROUND TAPPING	₹ 4	2
14	B9DF137V0000	GUIDE AIR 2	₹ 131	1
15	901090620200	BOLT	₹ 13	2
16	901100610200	BOLT, HEXAGON SOCKET HEAD	₹ 39	1
17	977075001200	SCREW TRUSS HD TAP	₹ 5	2
18	902690681200	RIVET	₹ 20	1
19	903380718000	PLUG	₹ 84	2
20	904800155900	GROMMET	₹ 10	1
21	904801062300	GROMMET	₹ 8	1
22	901830580700	NUT SPRING	₹ 9	2
23	B9DF83360000	PLATE	₹ 50	1
24	901600581000	SCREW, ROUND TAPPING	₹ 4	2
25	B9DXF83630P0	PANEL COMP 1	₹ 894	1
26	BCFF83910100	GRAPHIC 1	₹ 55	1
27	901830580700	NUT SPRING	₹ 9	2
28	B9DXF83G20P0	PANEL COMP 2	₹ 894	1
29	BCFF83920100	GRAPHIC 2	₹ 55	1
30	901830580700	NUT SPRING	₹ 9	2
31	B9DF83850000	COVER LOWER	₹ 180	1
32	901110686800	BOLT HEX. SOCKET BUTTON	₹ 26	2
33	903870689900	COLLAR	₹ 33	2
34	904801280800	GROMMET	₹ 10	2
35	977075001600	SCREW TRUSS HD.TAP	₹ 4	2
36	B9DF83950000	COVER UNDER	₹ 180	1
37	901110686800	BOLT HEX. SOCKET BUTTON	₹ 26	2
38	903870689900	COLLAR	₹ 33	2
39	904801280800	GROMMET	₹ 10	2
40	B9DF83650000	COVER	₹ 23	1
41	90109068B300	BOLT	₹ 19	1

Color Legend:

• Red: Canceled part - unavailable for any operations.
• Blue: Part of a kit - cannot be ordered individually.
• Gray (Dimmed): Disabled part - non-interactive for various reasons.
• Part Number : Superseded part - replaced by a newer part.

Description: - YAMAHA BCF4 MT15 V1 Series LEG SHIELD
