LEG SHIELD
BCW4
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BCWXF83610P0 | PANEL COMP 1 | ₹ 1859 | 1 | FOR SMX | |
| 2 | BCWF83914000 | GRAPHIC 1 | ₹ 40 | 1 | ||
| 3 | BCWF83934000 | GRAPHIC 3 | ₹ 126 | 1 | ||
| 4 | BCWF83983000 | GRAPHIC 5 | ₹ 185 | 1 | ||
| 5 | B9EF843H0000 | GRAPHIC 7 | ₹ 84 | 1 | ||
| 6 | 904640701800 | CLAMP | ₹ 6 | 1 | ||
| 7 | 901830580700 | NUT SPRING | ₹ 9 | 5 | ||
| 8 | 901110685900 | BOLT HEX. SOCKET BUTTON | ₹ 7 | 1 | ||
| 9 | BCWXF83G10P0 | PANEL COMP 2 | ₹ 1859 | 1 | FOR SMX | |
| 10 | BCWF83924000 | GRAPHIC 2 | ₹ 40 | 1 | ||
| 11 | BCWF83944000 | GRAPHIC 4 | ₹ 126 | 1 | ||
| 12 | BCWF83993000 | GRAPHIC 6 | ₹ 185 | 1 | ||
| 13 | B9EF844H0000 | GRAPHIC 8 | ₹ 77 | 1 | ||
| 14 | 904640701800 | CLAMP | ₹ 6 | 1 | ||
| 15 | 901830580700 | NUT SPRING | ₹ 9 | 5 | ||
| 16 | 901110685900 | BOLT HEX. SOCKET BUTTON | ₹ 7 | 1 | ||
| 17 | BCWF837L0000 | PANEL CONSOLE 1 | ₹ 66 | 1 | ||
| 18 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 19 | BCWF837M0000 | PANEL CONSOLE 2 | ₹ 66 | 1 | ||
| 20 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 21 | BCWXF83810P2 | UNDER COVER ASSY 1 | ₹ 1783 | 1 | FOR SMX | |
| 22 | BCWF83H20000 | GRAPHIC 1 | ₹ 87 | 1 | ||
| 23 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 24 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 25 | 904801280500 | GROMMET | ₹ 8 | 1 | ||
| 26 | 903870689900 | COLLAR | ₹ 30 | 1 | ||
| 27 | 901490682900 | SCREW | ₹ 25 | 1 | ||
| 28 | 901790684100 | NUT | ₹ 4 | 1 | ||
| 29 | BCWXF83910P2 | UNDER COVER ASSY 2 | ₹ 1783 | 1 | FOR SMX | |
| 30 | BCWF83H30000 | GRAPHIC 2 | ₹ 87 | 1 | ||
| 31 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 32 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 33 | 904801280500 | GROMMET | ₹ 8 | 1 | ||
| 34 | 903870689900 | COLLAR | ₹ 30 | 1 | ||
| 35 | 901490682900 | SCREW | ₹ 25 | 1 | ||
| 36 | 901790684100 | NUT | ₹ 4 | 1 | ||
| 37 | BCWF836K0000 | PANEL INNER 1 | ₹ 132 | 1 | ||
| 38 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 39 | 903380718000 | PLUG | ₹ 84 | 1 | ||
| 40 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 41 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 42 | BCWF836L0000 | PANEL INNER 2 | ₹ 132 | 1 | ||
| 43 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 44 | 903380718000 | PLUG | ₹ 84 | 1 | ||
| 45 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 2 | ||
| 46 | 902690681300 | RIVET | ₹ 8 | 2 | ||
| 47 | BCWF836M0000 | PANEL INNER 3 | ₹ 286 | 1 | ||
| 48 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 4 | ||
| 49 | 902690681300 | RIVET | ₹ 8 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The striking appearance of your Yamaha R15 V4 is enhanced by the detailed lines of this Leg Shield assembly. These panels provide critical protection for the engine while streamlining the airflow around the rider. The Panel Comp sections are manufactured from impact resistant materials to handle road debris. Every Under Cover Assy features a precise fit to shield the lower chassis from mud plus water. To maintain the factory fresh look, each Graphic is printed with UV resistant ink for long lasting color. Genuine body parts ensure that every mounting point aligns perfectly for a quiet, vibration free ride. This catalog provides the authentic replacements needed to keep your machine looking its best. Trust factory engineering for the quality plus durability your supersport deserves. Keep your motorcycle protected plus stylish on every single journey across the land.
