STEERING HANDLE & CABLE
0
BEP3
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | BEPF61100000 | HANDLE COMP. | ₹ 1150 | 1 | ||
| 2 | 901830580700 | NUT SPRING | ₹ 9 | 1 | ||
| 3 | 90105108C700 | BOLT FLANGE | ₹ 29 | 1 | ||
| 4 | 901851080400 | NUT SELF LOCKING | ₹ 15 | 1 | ||
| 5 | B7JF62410100 | GRIP | ₹ 55 | 1 | ||
| 6 | BEPF62400000 | GRIP ASSY | ₹ 155 | 1 | ||
| 7 | B5DF62460000 | END GRIP | ₹ 12 | 2 | ||
| 8 | B70F62800000 | REAR VIEW MIRROR ASSY (LEFT) | ₹ 225 | 1 | ||
| 9 | B70F62900000 | REAR VIEW MIRROR ASSY (RIGHT) | ₹ 225 | 1 | ||
| 10 | BEPF63010000 | THROTTLE CABLE ASSY | ₹ 857 | 1 | ||
| 11 | 920120501600 | BOLT, BUTTON HEAD | ₹ 12 | 1 | ||
| 12 | 913120501000 | BOLT | ₹ 8 | 2 | ||
| 13 | 904641080200 | CLAMP | ₹ 22 | 1 | ||
| 14 | 904641600600 | CLAMP | ₹ 59 | 3 | ||
| 15 | 904640780700 | CLAMP | ₹ 28 | 1 | ||
| 16 | BLVF63510000 | CABLE, BRAKE | ₹ 520 | 1 | ||
| 17 | BBPF637G0000 | HOLDER WIRE | ₹ 46 | 1 | ||
| 18 | 950220601200 | BOLT FLANGE | ₹ 8 | 1 | ||
| 19 | 905011680400 | SPRING COMPRESSION | ₹ 10 | 1 | ||
| 20 | 902491200800 | PIN | ₹ 20 | 1 | ||
| 21 | 901790680600 | NUT BRAKE | ₹ 17 | 1 | ||
| 22 | BEPF61430000 | COVER HANDLEBAR UPPER 1 | ₹ 116 | 1 | ||
| 23 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 24 | 902690681600 | RIVET | ₹ 14 | 2 | ||
| 25 | BEPF61450000 | COVER HANDLEBAR UPPER 2 | ₹ 116 | 1 | ||
| 26 | 903381826600 | PLUG | ₹ 163 | 1 | ||
| 27 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 28 | 977075001600 | SCREW TRUSS HD.TAP | ₹ 4 | 3 | ||
| 29 | 901830580100 | NUT SPRING | ₹ 9 | 2 | ||
| 30 | 905200180100 | SEAT PIPE | ₹ 5 | 2 | ||
| 31 | BEPF61AA0000 | VISOR | ₹ 210 | 1 | ||
| 32 | 901500502400 | SCREW ROUND HEAD | ₹ 59 | 4 | ||
| 33 | 901790580400 | NUT | ₹ 10 | 4 | ||
| 34A | BEPH355900P0 | COVER METER | ₹ 155 | 1 | ||
| 34B | BEPH355900P1 | COVER METER | ₹ 155 | 1 | ||
| 34C | BEPH3559003E | COVER METER | ₹ 155 | 1 | ||
| 35 | BEPF45490000 | EMBLEM | ₹ 37 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA BEP3 AEROX Series STEERING HANDLE & CABLE
