STEERING HANDLE & CABLE
0
BGPH
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B7JF61101000 | HANDLE COMP. | ₹ 746 | 1 | ||
| 2 | 901051029500 | BOLT FLANGE | ₹ 24 | 1 | ||
| 3 | 901851080400 | NUT SELF LOCKING | ₹ 15 | 1 | ||
| 4 | B7JF62410100 | GRIP | ₹ 55 | 1 | ||
| 5 | B7JF62400100 | GRIP ASSY | ₹ 75 | 1 | ||
| 6 | B7JF62460000 | END GRIP | ₹ 15 | 2 | ||
| 7 | B7JF62810000 | CAP GRIP UPPER | ₹ 30 | 1 | ||
| 8 | B7JF62820000 | CAP GRIP LOWER | ₹ 30 | 1 | ||
| 9 | 985020502500 | SCREW PAN HEAD | ₹ 4 | 2 | ||
| 10 | B7JF63110000 | CABLE THROTTLE 1 | ₹ 495 | 1 | ||
| 11 | 985070501600 | SCREW, PAN HEAD | ₹ 16 | 1 | ||
| 12 | 950220601200 | BOLT FLANGE | ₹ 8 | 1 | ||
| 13 | 904641080400 | CLAMP | ₹ 6 | 1 | ||
| 14 | B7JF63411100 | CABLE BRAKE | ₹ 255 | 1 | ||
| 15 | 905011281800 | SPRING COMPRESSION | ₹ 9 | 1 | ||
| 16 | B7JF63510100 | CABLE, BRAKE | ₹ 460 | 1 | ||
| 17 | 905011480200 | SPRING COMPRESSION | ₹ 8 | 1 | ||
| 18 | 901790680600 | NUT BRAKE | ₹ 17 | 1 | ||
| 19 | 902491200800 | PIN | ₹ 20 | 1 | ||
| 20A | B7JXF61410P5 | COVER HANDLE UPPE | ₹ 887 | 1 | ||
| 20B | B7JXF61400P8 | COVER HANDLE UPPE | ₹ 887 | 1 | ||
| 20C | B7JXF61410P3 | COVER HANDLE UPPE | ₹ 887 | 1 | ||
| 21 | B7JF45490000 | EMBLEM | ₹ 33 | 1 | ||
| 22 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 | ||
| 23 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 24 | B7JH45270000 | DAMPER | ₹ 4 | 2 | ||
| 25A | B7JF835A10P0 | RIM HEADLIGHT | ₹ 800 | 1 | ||
| 25B | B7JF835A0000 | RIM HEADLIGHT | ₹ 765 | 1 | ||
| 26 | B7JF61451000 | COVER HANDLEBAR UPPER 2 | ₹ 148 | 1 | ||
| 27 | 977025001200 | SCREW TAPPING | ₹ 11 | 4 | ||
| 28 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 29 | 901670507800 | SCREW, TAPPING | ₹ 25 | 4 | ||
| 30A | B7JH355900P2 | COVER METER SMX | ₹ 224 | 1 | ||
| 30B | B7JH355900P0 | COVER METER S8 | ₹ 224 | 1 | ||
| 31A | B7JF62801000 | REAR VIEW MIRROR ASSY (LEFT) | ₹ 413 | 1 | ||
| 31B | B7JF62800000 | REAR VIEW MIRROR ASSY (LEFT) | ₹ 458 | 1 | ||
| 32A | B7JF62901000 | REAR VIEW MIRROR ASSY (RIGHT) | ₹ 413 | 1 | ||
| 32B | B7JF62900000 | REAR VIEW MIRROR ASSY (RIGHT) | ₹ 458 | 1 | ||
| 33 | B7JF637G0000 | HOLDER, WIRE | ₹ 46 | 1 | ||
| 34 | B7JF14390000 | STOPPER MAIN STAND | ₹ 10 | 1 | ||
| 35 | 950220603500 | BOLT FLANGE | ₹ 11 | 1 | ||
| 36 | 950220601400 | BOLT FLANGE | ₹ 12 | 1 | ||
| 37 | B7JF637A0000 | COVER HANDLE LEVER 2 | ₹ 26 | 1 | ||
| 38 | B7JF63720100 | COVER, HANDLE LEVER 1 | ₹ 25 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA BGPH FASCINO 125 Series STEERING HANDLE & CABLE
