BGPV
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | B7JF516812P2 | CAST WHEEL, FRONT | ₹ 4701 | 1 | FOR MDRM4 | |
| 1B | B7JF5168128L | CAST WHEEL, FRONT | ₹ 3549 | 1 | FOR MBL2,MDPBM1 | |
| 2 | 93306300YN00 | BEARING | ₹ 124 | 2 | ||
| 3 | 903871084100 | COLLAR | ₹ 73 | 1 | ||
| 4 | 931062081300 | OIL SEAL | ₹ 103 | 1 | ||
| 5A | 941091281700 | TIRE | ₹ 2138 | 1 | ||
| 5B | 941091281600 | TIRE (3.00-18 6PR) | ₹ 0 | 1 | ||
| 6 | 939000082400 | VALVE RIM | ₹ 19 | 1 | ||
| 7 | 903871085100 | COLLAR | ₹ 40 | 1 | ||
| 8 | 90105108C400 | BOLT FLANGE | ₹ 100 | 1 | ||
| 9 | 956021020000 | NUT U FLANGE | ₹ 32 | 1 | ||
| 10 | B7JF51900100 | GEAR UNIT ASSY | ₹ 204 | 1 | ||
| 11 | B7JF51381100 | GEAR METER | ₹ 22 | 1 | ||
| 12 | 1GCF51360000 | BUSH | ₹ 3 | 1 | ||
| 13 | B7JF511B0000 | SEAL OIL | ₹ 50 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - The Yamaha Fascino Front Wheel assembly offers superior balance. This kit features a high-strength Cast Wheel, road-gripping Tire, and precision Bearings and Oil Seals. It also includes the Gear Unit Assy for the speedometer. Choosing this genuine wheel ensures steering geometry remains perfect, providing a confident feel whether cornering or cruising.
