FRONT WHEEL
BJE1/BFH1
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B9EF51680133 | CAST WHEEL FRONT | ₹ 5019 | 1 | ||
| 2 | 21CF510C1000 | COLLAR ASSY. | ₹ 27 | 1 | ||
| 3 | 931062280800 | OIL SEAL | ₹ 9 | 2 | ||
| 4 | 93306202XT00 | BEARING ( USE IN REAR WHEEL H | ₹ 185 | 2 | ||
| 5A | 941101781800 | TIRE FRONT ( 100/80-17 ) MRF | ₹ 1751 | 1 | ||
| 5B | 941101782400 | TIRE | ₹ 0 | 1 | ||
| 6 | 939000082400 | VALVE RIM | ₹ 19 | 1 | ||
| 7 | B9EF517G0000 | ROTOR SENSOR | ₹ 107 | 1 | ||
| 8 | 901490503000 | SCREW | ₹ 21 | 3 | ||
| 9 | 1CKF51860000 | COLLAR WHEEL | ₹ 23 | 2 | ||
| 10 | 21CF51810000 | AXLE WHEEL | ₹ 152 | 1 | ||
| 11 | 901851480000 | NUT SELF-LOCKING | ₹ 28 | 1 | ||
| 12 | 929071420000 | WASHER | ₹ 8 | 1 | ||
| 13A | 1CKF531B2000 | EMBLEM WHEEL | ₹ 27 | 2 | FOR MDRM4 | |
| 13B | 1CKF531B3000 | EMBLEM WHEEL | ₹ 80 | 2 | FOR MDPBM1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - agility plus steering accuracy for the Yamaha FZS V3 begin at the front wheel assembly. rotating on high quality bearing units, the cast wheel provides a stable, vibration free experience on Indian roads. to protect the internal parts, the oil seal creates a robust barrier against dust, water. the axle wheel provides the necessary support; it anchors the entire setup to the forks with absolute stability. this lightweight design reduces unsprung weight; it allows the suspension to respond effectively to bumps. every collar plus washer is precision machined to ensure a perfect fitment. maintaining the balance of this wheel is vital for preserving the sharp handling dynamics of the street fighter. a well maintained front wheel ensures every rider input is translated into accurate direction changes. experience the confidence of a perfectly aligned front end; it provides the grip needed for every turn throughout your journey on the motorcycle.
