FRONT WHEEL
BKH5
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | B9EF51680133 | CAST WHEEL FRONT | ₹ 5019 | 1 | FOR SMX,MDOM3 | |
| 1B | B9EF5168018L | CAST WHEEL FRONT | ₹ 5019 | 1 | FOR MDPBM1 | |
| 1C | B9EF516801P6 | CAST WHEEL, FRONT | ₹ 5213 | 1 | FOR MT2 | |
| 2 | 21CF510C1000 | COLLAR ASSY. | ₹ 27 | 1 | ||
| 3 | 931062280800 | OIL SEAL | ₹ 9 | 2 | ||
| 4 | 93306202XT00 | BEARING ( USE IN REAR WHEEL H | ₹ 185 | 2 | ||
| 5 | 941101783000 | TIRE (100/80-17 M/C 52P) | ₹ 0 | 1 | ||
| 6 | 939000082400 | VALVE RIM | ₹ 19 | 1 | ||
| 7 | B9EF517G0000 | ROTOR SENSOR | ₹ 107 | 1 | ||
| 8 | 901490503000 | SCREW | ₹ 21 | 3 | ||
| 9 | 1CKF51860000 | COLLAR WHEEL | ₹ 23 | 2 | ||
| 10 | 21CF51810000 | AXLE WHEEL | ₹ 152 | 1 | ||
| 11 | 901851480000 | NUT SELF-LOCKING | ₹ 28 | 1 | ||
| 12 | 929071420000 | WASHER | ₹ 8 | 1 | ||
| 13 | BCLF51880000 | CAP | ₹ 9 | 1 | ||
| 14 | BCLF531B0000 | EMBLEM WHEEL | ₹ 25 | 2 | FOR MDOM3 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Precise steering plus stability start with the engineering excellence of the Front Wheel assembly. This setup features the lightweight plus strong Cast Wheel Front, designed to offer superior strength plus a modern aesthetic look. The assembly includes high quality Bearings plus an Oil Seal to ensure smooth rotation plus protection from environmental contaminants found on the road. The Axle Wheel plus Nut Self Locking provide a secure connection to the front suspension, while the Washer plus Cap provide a professional finish. A high traction Tire ensures maximum grip during cornering plus braking on all Indian road surfaces. The integrated Rotor Sensor plus Screw setup provide critical speed information to your dashboard plus safety systems. Every component in this front wheel assembly is built to provide the reliability plus performance needed for a superior riding experience, ensuring every journey is smooth plus controlled for the rider.
