STEERING HANDLE & CABLE
0
BKX3
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B2UF61100000 | HANDLE COMP. | ₹ 693 | 1 | ||
| 2 | 901051029500 | BOLT FLANGE | ₹ 24 | 1 | ||
| 3 | 901851080400 | NUT SELF LOCKING | ₹ 15 | 1 | ||
| 4 | B7JF62410100 | GRIP | ₹ 55 | 1 | ||
| 5 | B7JF62400100 | GRIP ASSY | ₹ 75 | 1 | ||
| 6 | B2UF62460000 | END GRIP | ₹ 14 | 2 | ||
| 7 | B7JF62810000 | CAP GRIP UPPER | ₹ 30 | 1 | ||
| 8 | B7JF62820000 | CAP GRIP LOWER | ₹ 30 | 1 | ||
| 9 | 985020502500 | SCREW PAN HEAD | ₹ 4 | 2 | ||
| 10 | B7JF63110000 | CABLE THROTTLE 1 | ₹ 495 | 1 | ||
| 11 | 985070501600 | SCREW, PAN HEAD | ₹ 16 | 1 | ||
| 12 | 950220601200 | BOLT FLANGE | ₹ 8 | 1 | ||
| 13 | 904641080400 | CLAMP | ₹ 6 | 1 | ||
| 14 | B7JF63411100 | CABLE BRAKE | ₹ 255 | 1 | ||
| 15 | 905011281800 | SPRING COMPRESSION | ₹ 9 | 1 | ||
| 16 | B7JF63510100 | CABLE, BRAKE | ₹ 460 | 1 | ||
| 17 | 905011480200 | SPRING COMPRESSION | ₹ 8 | 1 | ||
| 18 | 901790680600 | NUT BRAKE | ₹ 17 | 1 | ||
| 19 | 902491200800 | PIN | ₹ 20 | 1 | ||
| 20 | B2UF61430000 | COVER HANDLEBAR UPPER 1 | ₹ 700 | 1 | ||
| 21 | 977025001200 | SCREW TAPPING | ₹ 11 | 2 | ||
| 22 | 977025001600 | SCREW TAPPING | ₹ 10 | 3 | ||
| 23 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 24 | B2UF62310000 | COVER HANDLE FRONT | ₹ 33 | 1 | ||
| 25 | B2UF62340000 | SCREEN | ₹ 225 | 1 | ||
| 26 | 901500502400 | SCREW ROUND HEAD | ₹ 59 | 4 | ||
| 27 | 901790580400 | NUT | ₹ 10 | 4 | ||
| 28 | B2UF61450100 | COVER, HANDLE 2 | ₹ 180 | 1 | ||
| 29 | 977025001200 | SCREW TAPPING | ₹ 11 | 4 | ||
| 30 | 901830580700 | NUT SPRING | ₹ 9 | 2 | ||
| 31 | 901670507800 | SCREW, TAPPING | ₹ 25 | 4 | ||
| 32A | B2UH355900P5 | COVER METER | ₹ 225 | 1 | ||
| 32B | B2UH355900P0 | COVER METER | ₹ 204 | 1 | ||
| 32C | B2UH355900P4 | COVER METER | ₹ 225 | 1 | ||
| 33 | 977025001200 | SCREW TAPPING | ₹ 11 | 1 | ||
| 34 | B2UF62800000 | REAR VIEW MIRROR ASSY (LEFT) | ₹ 219 | 1 | ||
| 35 | B2UF62900000 | REAR VIEW MIRROR ASSY (RIGHT) | ₹ 219 | 1 | ||
| 36 | B7JF637G0000 | HOLDER, WIRE | ₹ 46 | 1 | ||
| 37 | B7JF14390000 | STOPPER MAIN STAND | ₹ 10 | 1 | ||
| 38 | 950220603500 | BOLT FLANGE | ₹ 11 | 1 | ||
| 39 | 950220601400 | BOLT FLANGE | ₹ 12 | 1 | ||
| 40 | B7JF637A0000 | COVER HANDLE LEVER 2 | ₹ 26 | 1 | ||
| 41 | B7JF63720100 | COVER, HANDLE LEVER 1 | ₹ 25 | 1 | ||
| 42 | B2UF612B0000 | STAY STEM HANDLE L | ₹ 105 | 1 | ||
| 43 | B2UF63560000 | BOLT ADJUSTING | ₹ 25 | 1 | ||
| 44 | 929071060000 | WASHER | ₹ 10 | 1 | ||
| 45 | B2UF61410000 | GUARD BRUSH 1 | ₹ 55 | 1 | ||
| 46 | 901090580300 | BOLT | ₹ 6 | 2 | ||
| 47 | B2UF612C0000 | STAY STEM HANDLE R | ₹ 100 | 1 | ||
| 48 | B2UF63860000 | BOLT ADJUSTING | ₹ 25 | 1 | ||
| 49 | 929071060000 | WASHER | ₹ 10 | 1 | ||
| 50 | B2UF61420000 | GUARD BRUSH 2 | ₹ 55 | 1 | ||
| 51 | 901090580300 | BOLT | ₹ 6 | 2 | ||
| 52 | B7JF45490000 | EMBLEM | ₹ 33 | 1 | ||
| 53 | B4GF836B0000 | TUNING FORK MARK | ₹ 15 | 1 | ||
| 54 | 904643680000 | CLAMP | ₹ 8 | 1 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA BKX3 RAYZR 125 Series STEERING HANDLE & CABLE
