FENDER
0
BKX6
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1A | B2UXF15120P3 | FENDER FRONT | ₹ 860 | 1 | ||
| 1B | B2UXF15120P1 | FENDER FRONT | ₹ 860 | 1 | ||
| 1C | B2UXF15120P2 | FENDER FRONT | ₹ 860 | 1 | ||
| 2 | B7JF15410000 | DAMPER 1 | ₹ 10 | 1 | ||
| 3 | 90387068T800 | COLLAR | ₹ 18 | 3 | ||
| 4 | 958120601600 | BOLT FLANGE | ₹ 3 | 3 | ||
| 5 | B2UF16110000 | FENDER REAR | ₹ 344 | 1 | ||
| 6 | 90387068S100 | COLLAR | ₹ 14 | 4 | ||
| 7 | 958120601400 | BOLT, FLANGE | ₹ 5 | 4 | ||
| 8 | B7JF16210100 | FLAP | ₹ 25 | 1 | ||
| 9 | B7JF16910100 | FLAP | ₹ 35 | 1 | ||
| 10 | 901830506700 | NUT SPRING | ₹ 8 | 1 | ||
| 11 | 901830580700 | NUT SPRING | ₹ 9 | 4 | ||
| 12 | 2FCH51110000 | REFLECTOR FRONT 1 | ₹ 26 | 2 | ||
| 13 | 957070550000 | NUT FLANGE | ₹ 1 | 2 | ||
| 14 | B2UF16510000 | COVER REAR FENDER | ₹ 46 | 1 | ||
| 15 | 977025001600 | SCREW TAPPING | ₹ 10 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - YAMAHA BKX6 RAY ZR 125 Series FENDER
