BKXE
| Ref No | Part No | Part Name | Rate | Qnty | Order | Remarks |
|---|---|---|---|---|---|---|
| 1 | B2UH33100000 | FRONT FLASHER LIGHT ASSY 1 | ₹ 219 | 1 | ||
| 2 | 54BH331A0000 | LENS COMP 1-CLEAR | ₹ 50 | 1 | ||
| 3 | 2FBH33110000 | BULB FLASHER M12/6 | ₹ 35 | 1 | ||
| 4 | 20PH33180000 | STAY FLASHER 1 | ₹ 24 | 1 | ||
| 5 | B2UH331E0000 | CORD ASSY | ₹ 29 | 1 | ||
| 6 | 20PH213A0000 | SCREW, FITTING | ₹ 1 | 1 | ||
| 7 | 20PH36180000 | PLATE | ₹ 4 | 1 | ||
| 8 | 20PH33330000 | SCREW LENS FITTING | ₹ 1 | 1 | ||
| 9 | 20PH21330000 | SCREW FITTING | ₹ 1 | 1 | ||
| 10 | B2UH33200000 | FRONT FLASHER LIGHT ASSY 2 | ₹ 219 | 1 | ||
| 11 | 54BH332A0000 | LENS COMP 2-CLEAR | ₹ 50 | 1 | ||
| 12 | 2FBH33110000 | BULB FLASHER M12/6 | ₹ 35 | 1 | ||
| 13 | 20PH33180000 | STAY FLASHER 1 | ₹ 24 | 1 | ||
| 14 | B2UH332E0000 | CORD ASSY | ₹ 35 | 1 | ||
| 15 | 20PH36180000 | PLATE | ₹ 4 | 1 | ||
| 16 | 20PH213A0000 | SCREW, FITTING | ₹ 1 | 1 | ||
| 17 | 20PH33330000 | SCREW LENS FITTING | ₹ 1 | 1 | ||
| 18 | 20PH21330000 | SCREW FITTING | ₹ 1 | 1 | ||
| 19 | 5YYH33181000 | STAY FLASHER 1(LOCK) | ₹ 4 | 2 | ||
| 20 | B2UH33300000 | REAR FLASHER LIGHT ASSY 1 | ₹ 219 | 1 | ||
| 21 | 54BH334A0000 | LENS COMP-CLEAR | ₹ 50 | 1 | ||
| 22 | 2FBH33110000 | BULB FLASHER M12/6 | ₹ 35 | 1 | ||
| 23 | 20PH33181000 | STAY FLASHER 1 | ₹ 27 | 1 | ||
| 24 | B2UH333E0000 | CORD ASS'Y | ₹ 35 | 1 | ||
| 25 | 20PH36180000 | PLATE | ₹ 4 | 1 | ||
| 26 | 20PH213A0000 | SCREW, FITTING | ₹ 1 | 1 | ||
| 27 | 20PH33330000 | SCREW LENS FITTING | ₹ 1 | 1 | ||
| 28 | 20PH21330000 | SCREW FITTING | ₹ 1 | 1 | ||
| 29 | B2UH33400000 | FLASHER LIGHT ASSY 2 | ₹ 219 | 1 | ||
| 30 | 54BH333A0000 | LENS COMP-CLEAR | ₹ 50 | 1 | ||
| 31 | 2FBH33110000 | BULB FLASHER M12/6 | ₹ 35 | 1 | ||
| 32 | 20PH33181000 | STAY FLASHER 1 | ₹ 27 | 1 | ||
| 33 | B2UH334E0000 | CORD ASS'Y | ₹ 35 | 1 | ||
| 34 | 20PH36180000 | PLATE | ₹ 4 | 1 | ||
| 35 | 20PH213A0000 | SCREW, FITTING | ₹ 1 | 1 | ||
| 36 | 20PH33330000 | SCREW LENS FITTING | ₹ 1 | 1 | ||
| 37 | 20PH21330000 | SCREW FITTING | ₹ 1 | 1 | ||
| 38 | 5YYH33181000 | STAY FLASHER 1(LOCK) | ₹ 4 | 2 |
Color Legend:
- Red: Canceled part - unavailable for any operations.
- Blue: Part of a kit - cannot be ordered individually.
- Gray (Dimmed): Disabled part - non-interactive for various reasons.
- Part Number : Superseded part - replaced by a newer part.
Description: - Signalling your turns with clarity is key to urban safety, and the BKXE Flasher Light assembly delivers comprehensive coverage. This set includes the Front Flasher Light Assy 1 and 2, along with the Rear Flasher Light Assy 1 and 2. Each unit is equipped with a high-output Bulb Flasher M12/6 and protected by a Lens Comp (Clear) for maximum visibility and a modern look. The kit is built for long-term durability, featuring the Stay Flasher 1 (Lock), Plate, and specialized Screw Fitting hardware for a secure mount. We’ve also included the specific Cord Assy and Screw Lens Fitting components for a seamless electrical integration. These signals are designed to be bright and responsive, providing the technical clarity and purchase confidence required for safe lane changes and maneuvers. Don’t settle for dim imitations; choose the genuine Yamaha flasher set for professional performance and the confidence of being seen in any weather. Every part is factory-engineered for perfection, ensuring your machines safety systems operate perfectly.
